Intel® Server Board X38ML
Pin-Side B
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
Revision 1.3
PCI Spec Signal Pin-Side A
PRSNT2_N 17
GND 18
PETP1 19
PETN1 20
GND 21
GND 22
PETP2 23
PETN2 24
GND 25
GND 26
PETP3 27
PETN3 28
GND 29
RSVD 30
PRSNT2_N 31
GND 32
PETP4 33
PETN4 34
GND 35
GND 36
PETP5 37
PETN5 38
GND 39
GND 40
PETP6 41
PETN6 42
GND 43
GND 44
PETP7 45
PETN7 46
GND 47
PRSNT2_N 48
GND 49
PETP8 50
PETN8 51
GND 52
GND 53
PETP9 54
PETN9 55
GND 56
GND 57
PETP10 58
PETN10 59
GND 60
GND 61
Intel order number E15331-006
Connectors and Jumper Blocks
PCI Spec Signal
PERN0
GND
RSVD
GND
PERP1
PERN1
GND
GND
PERP2
PERN2
GND
GND
PERP3
PERN3
GND
RSVD
RSVD
GND
PERP4
PERN4
GND
GND
PERP5
PERN5
GND
GND
PERP6
PERN6
GND
GND
PERP7
PERN7
GND
RSVD
GND
PERP8
PERN8
GND
GND
PERP9
PERN9
GND
GND
PERP10
PERN10
