Summary of Contents for Intel SE7320VP2
- Page 1 Intel® Server Board SE7320VP2 User Guide Order Number: C71354-002...
- Page 2 Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions.
-
Page 3: About This Manual
Manual Organization Chapter 1 provides a brief overview of the Server Board SE7320VP2. In this chapter, you will find a list of the server board features, photos of the product, and product diagrams to help you identify components and their locations. -
Page 4: Additional Information And Software
Search for “Technical Product Specification” about this product, including BIOS settings and chipset information If you just received this product and See the Intel® Server Board SE7320VP2 Quick Start User’s Guide in the need to install it product box For virtual system tours and Use the link to the SMaRT Tool under “Other Resources”... -
Page 5: Safety Information
To ensure EMC compliance with your local regional rules and regulations, the final configuration of your end system product may require additional EMC compliance testing. For more information please contact your local Intel Representative. “Regulatory and Integration Information” for product safety compliance and EMC regulatory compliance information. - Page 6 Preface Warnings System power on/off: The power button DOES NOT turn off the system AC power. To remove power from system, you must unplug the AC power cord from the wall outlet. Make sure the AC power cord is unplugged before you open the chassis, add, or remove any components.
-
Page 7: Safety Cautions
Safety Cautions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http://support.intel.com/support/motherboards/server/. SAFETY STEPS: Whenever you remove the chassis covers to access the inside of the system, follow these steps: Turn off all peripheral devices connected to the system. - Page 8 Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le CD Resource CD ou bien rendez-vous sur le site http://support.intel.com/support/motherboards/server/.
- Page 9 Instrucciones de seguridad importantes Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en el CD Resource y/o en http://support.intel.com/support/motherboards/server/. INSTRUCCIONES DE SEGURIDAD: Cuando extraiga la tapa del chasis para acceder al interior del sistema, siga las siguientes instrucciones: Apague todos los dispositivos periféricos conectados al sistema.
- Page 10 Preface...
-
Page 11: Table Of Contents
Contents Contents 1 Server Board Features................. 15 Connector and Header Locations ..................17 Configuration Jumpers ......................18 Back Panel Connectors......................21 Hardware Requirements ....................... 22 Processor ........................22 Memory ........................22 Optional Hardware ........................ 24 Storage Devices ......................24 2 Hardware Installations and Upgrades ............25 Before You Begin ........................ - Page 12 Intel Server Issue Report Form............... 55 Figures Figure 1. Intel ® Server Board SE7320VP2................15 Figure 2. Server Board Connector and Header Locations............17 Figure 3. Recovery Jumper Location ..................18 Figure 4. Serial Port Configuration Jumper Location ..............19 Figure 5.
- Page 13 Contents Tables Table 1. Server Board Features .................. 16 Table 2. Recovery Jumper [J1H2, J1H3, J1H5] ............18 Table 3. Serial Port Configuration Jumper [J8A3] ............19 Table 4. BIOS Select Jumper [J1A4]................20 Table 5. NIC LEDs....................... 21 Table 6. Processor Support..................
- Page 14 Contents...
-
Page 15: Server Board Features
The Server Board SE7320VP2 is shown in the following picture. ® Figure 1. Intel Server Board SE7320VP2 Intel®... -
Page 16: Table 1. Server Board Features
Server Board Features Feature Description Processors Support for up to two Intel® Xeon™ processors with an 800 MT/s MHz front side bus and frequencies starting at 2.8 GHz. Memory Six DIMM slots supporting DDR266MHz or DDR333MHz memory Memory mirroring and memory sparing options Chipset Intel®... -
Page 17: Connector And Header Locations
Server Board Features Connector and Header Locations TP00941 A Serial Port A header K Processor 2 fan header Configuration jumpers B Battery SATA 1 connector +12V processor power connector C Full-height PCI slot Fan board connector W SATA 0 connector D Low-profile PCI slot Floppy connector Power supply connector... -
Page 18: Configuration Jumpers
Server Board Features Configuration Jumpers Recovery Jumpers J1H2, J1H3, J1H5 J1H2 Pass Clr Protect Erase J1H3 Rcvr Boot Recovery Boot Normal Boot J1H5 CMOS Clr BMC Control Force Erase TP00942 Figure 3. Recovery Jumper Location Table 2. Recovery Jumper [J1H2, J1H3, J1H5] Jumper Name Pins What happens at system reset…... -
Page 19: Figure 4. Serial Port Configuration Jumper Location
Server Board Features Serial Port Configuration Jumper J8A3 1-3: DCD to DTR (Default) 2-4: DSR to DTR TP00944 Figure 4. Serial Port Configuration Jumper Location Table 3. Serial Port Configuration Jumper [J8A3] Pins What happens at system reset… Serial port is configured for DCD to DTR (default) Serial port is configured for DSR to DTR. -
Page 20: Figure 5. Bios Select Jumper Location
Server Board Features BIOS Select Jumper J1A4 BIOS Select 1-2: Normal Operation (Default) 2-3: Force to Lower Bank TP00949 Figure 5. BIOS Select Jumper Location Table 4. BIOS Select Jumper [J1A4] Pins What happens at system reset… System is configured for normal operation Force BIOS to lower bank... -
Page 21: Back Panel Connectors
Server Board Features Back Panel Connectors TP00943 A Mouse NIC2 (1 Gb) B Keyboard Video C Serial Port B USB1 D NIC1 (1 Gb) USB2 Figure 6. Back Panel Connectors The NIC LEDs at the right and left of each NIC provide the following information. Table 5. -
Page 22: Hardware Requirements
Software.” Processor One or two Intel® Xeon™ processors with an 800MHz front side bus and a minimum of 2.8 GHz frequency must be installed. The following table outlines the supported processors. For a complete list of supported processors, see the links under “Additional Information and... -
Page 23: Table 7. Memory Capacity Support
Software.” Memory Sparing and Mirroring The Intel® E7320 chipset supports memory mirroring and memory on-line sparing. Both memory mirroring and memory on-line sparing provide a way to prevent data loss in case a DIMM fails. With memory mirroring the system maintains two copies of all data in the memory subsystem. If a DIMM fails, the data is not lost because the second copy of the data is available from the mirrored DIMM in the opposite channel. -
Page 24: Optional Hardware
Optional Hardware Storage Devices The Server Board SE7320VP2 provides two SATA connections and two ATA (IDE/ATAPI) controllers. The two SATA connectors are on the powersupply side of the board marked “SATA 0” and “SATA 1”. Each ATA connection supports one or two ATA/100 devices. IDE devices can be connected to the standard ATA connector, next to the floppy connector, or to the 100-pin cable connector. -
Page 25: Hardware Installations And Upgrades
1. Observe the safety and ESD precautions at the beginning of this book. 2. Turn off all peripheral devices connected to the server. Turn off the server. 3. Disconnect the AC power cord from the server. Intel® Server Board SE7320VP2 User Guide... -
Page 26: Figure 7. Installing Memory
Hardware Installations and Upgrades 4. Remove the server’s cover. See the documentation that accompanied your server chassis for instructions on removing the server’s cover. 5. Locate the DIMM sockets (see Figure 7). DIMM 2A DIMM 2B DIMM 3B DIMM 1A DIMM 3A DIMM 1B TP00761... -
Page 27: Removing Dimms
Hardware Installations and Upgrades Removing DIMMs To remove a DIMM, follow these steps: 1. Observe the safety and ESD precautions at the beginning of this book. 2. Turn off all peripheral devices connected to the server. Turn off the server. 3. -
Page 28: Installing Or Replacing The Processor
Hardware Installations and Upgrades Installing or Replacing the Processor CAUTIONS Processor must be appropriate: You may damage the server board if you install a processor that is inappropriate for your server. See “Additional Information and Software” for a link to the list of compatible processor(s). ESD and handling processors: Reduce the risk of electrostatic discharge (ESD) damage to the processor by doing the following: (1) Touch the metal chassis before touching the processor or server board. -
Page 29: Figure 9. Inserting Processor
Hardware Installations and Upgrades 6. Align the pins of the processor with the socket, and insert the processor into the socket. ✏ NOTE Make sure the alignment triangle mark and the alignment triangle cutout align correctly. TP00764 Figure 9. Inserting Processor 7. -
Page 30: Removing A Processor
Hardware Installations and Upgrades Installing the Heat Sink(s) 1. The heat sink has Thermal Interface Material (TIM) located on the bottom of it. Use caution when you unpack the heat sink so you do not damage the TIM. 2. Set the heat sink over the processor, lining up the four captive screws with the four posts surrounding the processor. -
Page 31: Rj45 Serial Port Configuration
Hardware Installations and Upgrades 8. Lift the heat sink from the processor. If it does not pull up easily, twist the heat sink again. Do not force the heat sink from the processor. Doing so could damage the processor. 9. Lift the processor lever. 10. -
Page 32: Installing A Pci, Pci-X, Or Pci-Express* Add-In Card
Hardware Installations and Upgrades Installing a PCI, PCI-X, or PCI-Express* Add-in Card Add-in cards are not included with your system and must be purchased separately. This server board requires the use of a riser bracket assembly with one or more riser connectors installed on it in order to use a PCI, PCI-X, or PCI-Express add-in card. -
Page 33: Figure 13. Replacing The Backup Battery
Hardware Installations and Upgrades VAROITUS Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. 1. Observe the safety and ESD precautions at the beginning of this book. 2. Turn off all peripheral devices connected to the server. Turn off the server. 3. -
Page 34: Server Utilities
These parameters can be changed if the user has adequate security rights. If a value cannot be changed for any reason, the feature’s value field is inaccessible. Table 8 describes the keyboard commands you can use in the BIOS Setup menus. Intel® Server Board SE7320VP2 User Guide... -
Page 35: Table 8. Keyboard Commands
Server Utilities Table 8. Keyboard Commands Press Description <F1> Help - Pressing F1 on any menu invokes the general Help window. The left and right arrow keys are used to move between the major menu pages. The keys have no affect if a submenu or pick list is displayed. Select Item up - The up arrow is used to select the previous value in a menu item’s option list, or a value field pick list. -
Page 36: Upgrading The Bios
Server Utilities Upgrading the BIOS The upgrade utility allows you to upgrade the BIOS in flash memory. The code and data in the upgrade file include the following: On-board system BIOS, including the recovery code, BIOS Setup Utility, and strings. On-board video BIOS and other option ROMs for devices embedded on the server board. -
Page 37: Upgrading The Bios
Server Utilities Upgrading the BIOS Follow the instructions in the readme file that came with the BIOS upgrade. When the update completes, remove the bootable media from which you performed the upgrade. ✏ NOTES Do not power down the system during the BIOS update process! The system will reset automatically when the BIOS update process is completed. -
Page 38: Clearing The Cmos
Server Utilities 4. Reconnect the AC power, power up the system. 5. Power down the system and disconnect the AC power. 6. Return the Password Clear jumper to the Password Clear Protect position, covering pins 2 and 3. 7. Close the server chassis. 8. -
Page 39: Troubleshooting
SCSI drivers. Intel provides a package called the “Platform Confidence Test” that may help with your diagnostics. See “Additional Information and... -
Page 40: Problems Following Initial System Installation
Troubleshooting Problems following Initial System Installation Problems that occur at initial system startup are usually caused by an incorrect installation or configuration. Hardware failure is a less frequent cause. If the problem you are experiencing is with a specific software application, see “Problems with Newly Installed Application Software.”... -
Page 41: Hardware Diagnostic Testing
Troubleshooting Hardware Diagnostic Testing This section provides a more detailed approach to identifying a hardware problem and locating its source. CAUTION Turn off devices before disconnecting cables: Before disconnecting any peripheral cables from the system, turn off the system and any external peripheral devices. -
Page 42: Specific Problems And Corrective Actions
Troubleshooting Specific Problems and Corrective Actions This section provides possible solutions for these specific problems: Power light does not light. No characters appear on screen. Characters on the screen appear distorted or incorrect. System cooling fans do not rotate. Diskette drive activity light does not light. Hard disk drive activity light does not light. -
Page 43: No Characters Appear On Screen
Troubleshooting No Characters Appear on Screen Check the following: Is the keyboard functioning? Test it by turning the “Num Lock” function on and off to make sure the Num Lock light is functioning. Is the video monitor plugged in and turned on? If you are using a switch box, is it switched to the correct system? Are the brightness and contrast controls on the video monitor properly adjusted? Is the video monitor signal cable properly installed? -
Page 44: System Cooling Fans Do Not Rotate Properly
Troubleshooting System Cooling Fans Do Not Rotate Properly If the system cooling fans are not operating properly, it is an indication of possible system component failure. Check the following: Is the power-on light lit? If not, see “Power Light Does Not Light”... -
Page 45: Cd-Rom Drive Or Dvd-Rom Drive Activity Light Does Not Light
Troubleshooting CD-ROM Drive or DVD-ROM Drive Activity Light Does Not Light Check the following: Are the CD-ROM/DVD-ROM drive’s power and signal cables properly installed? Are all relevant switches and jumpers on the drive set correctly? Is the drive properly configured? Cannot Connect to a Server Make sure the network cable is securely attached to the correct connector at the system back panel. -
Page 46: System Boots When Installing Pci Card
Troubleshooting The add-in adapter stopped working without apparent cause. Try reseating the adapter first; then try a different slot if necessary. The network driver files may be corrupt or deleted. Delete and then reinstall the drivers. Run the diagnostics. System Boots when Installing PCI Card System Server Management features require full-time “standby”... -
Page 47: Devices Are Not Recognized Under Device Manager (Windows* Operating System)
Devices are not Recognized under Device Manager (Windows* Operating System) The Windows* operating systems do not include all of the drivers for the Intel® chipsets, onboard NICs, and other components. See “Additional Information and Software”... -
Page 48: Led Information
Troubleshooting LED Information ® The Intel Server Board SE7320VP2 includes LEDs that can aid in troubleshooting your system. A table of these LEDs with a description of their use is listed below. Table 9. Keyboard Commands LED Name Function Location... -
Page 49: Product Regulatory Compliance
Intel targets 10db margin to Class A Limits. The Server Board SE7320VP2 has been has been tested and verified to comply with the following ® electromagnetic compatibility (EMC) regulations when installed a compatible Intel host system. -
Page 50: Certifications / Registrations / Declarations
Regulatory and Compliance Information Certifications / Registrations / Declarations UL Certification (US/Canada) CE Declaration of Conformity (CENELEC Europe) FCC/ICES-003 Class A Attestation (USA/Canada) C-Tick Declaration of Conformity (Australia) MED Declaration of Conformity (New Zealand) BSMI Certification (Taiwan) GOST – Listed on one System License (Russia) Belarus –... -
Page 51: Electromagnetic Compatibility Notices
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124-6497... -
Page 52: Industry Canada (Ices-003)
English translation of the notice above: 1. Type of Equipment (Model Name): On License and Product 2. Certification No.: On RRL certificate. Obtain certificate from local Intel representative 3. Name of Certification Recipient: Intel Corporation 4. Date of Manufacturer: Refer to date code on product... -
Page 53: Getting Help
Telephone All calls are billed US $25.00 per incident, levied in local currency at the applicable credit card exchange rate plus applicable taxes. (Intel reserves the right to change the pricing for telephone support at any time without notice). Before calling, fill out an “Intel®... - Page 54 SA at 800 800 311. Once connected, dial 800 843 4481 Chile (Mainland and Juan) Contact AT&T USA at 800 225 288. Once connected, dial 800 843 4481 Miami 1 800 621 8423 For an updated support contact list, see http://www.intel.com/support/9089.htm/...
-
Page 55: Intel Server Issue Report Form
System BIOS Version: DIMM2A MB: HSC Firmware Version: DIMM2A Vendor / part number: Chassis Model DIMM2B MB: Intel Server Chassis SR2400r DIMM2B Vendor / part number: Intel Server Platform SR1435VP2 DIMM3A MB Other (Vendor / Model): DIMM3B Vendor / part number... - Page 56 Issue Report Form Operating System Information Operating System Version Service Pack Peripheral Information Check each box below that is used, and provide the requested information Peripheral Card or Peripheral Description Driver IRQ # I/O Base FW Rev# Revision Address Low-profile Riser Top slot Center slot Bottom slot...
- Page 57 Complete Problem Description In the space below, provide a complete description of the steps used to reproduce the problem or a complete description of where the problem can be found. Please also include any details on troubleshooting already done.
