- Page 1 ® Intel Server Board SE7501WV2 Tested Hardware and Operating System List Revision 3.5 June 2006 Enterprise Platforms and Services Marketing...
-
Page 2: Revision History
Revision History Intel® Server Board SE7501WV2 Revision History Revision Date Number Modifications January 2003 Initial Draft February 2003 Adding additional validated parts. Testing is still in process. March 2003 Adding SCSI & ATA validated parts. March 2003 Removed 3COM 3C996B-T card. Removed Adaptec “code” names. - Page 3 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
-
Page 4: Table Of Contents
Samsung SP8004H Polaris 40 hard drive jumpers should be removed for proper sizing44 Red Hat Linux* 7.3 segmentation fault with an Intel® RAID controller installed .... 44 Red Hat Linux* 8.0 segmentation fault with an Intel® RAID controller installed .... 45... -
Page 5: Introduction
Introduction Introduction This document is intended to provide users of the Intel® server board SE7501WV2 with a guide to the different operating systems, adapter cards, and peripherals tested by Intel on this platform. This document will continue to be updated as new add-in cards, peripherals, and operating systems are tested or until the Intel server board SE7501WV2 is no longer in production. -
Page 6: Stress Testing
Files copied from client to server and back compare to the original with zero errors reported. Clients remain connected to the server system. Industry standard test suites run to completion with zero errors reported. Intel server board SE7501WV2 testing was performed using the Intel server chassis SR1300 & SR2300. Revision 3.5... -
Page 7: Intel Server Board Se7501Wv2 Base System Configurations
Intel® Server Board SE7501WV2 Intel® Server Board SE7501WV2 Base System Configurations ® Intel Server Board SE7501WV2 Base System Configurations The following table lists the base configurations tested. Base configurations will change as new ® revisions of the Intel server board SE7501WV2 are released and/or new system BIOS and BMC firmware are cut onto the board in the factory. -
Page 8: Supported Operating Systems
The following table provides a list of supported operating systems for the Intel server board SE7501WV2. Each of the listed operating systems was tested for compatibility with a base Intel server board SE7501WV2 configuration. Operating system compatibility testing verifies that the operating system will install and function with all on-board devices. -
Page 9: Operating System Certifications
However, the customer is responsible for their own certification from the individual operating system vendors. In many cases, the customer may leverage their operating system certifications from Intel’s testing. See the “Comments” section next to each operating system in the table below for additional information. Intel’s certifications, pre-certification, and operating system testing may help reduce some of the risk in achieving customer certifications with the operating system vendors. - Page 10 Supported Operating Systems Intel® Server Board SE7501WV2 Operating System Certification Listing Comments SuSE checks Intel’s results, certifies (if appropriate), and posts the certificate on their web site. Intel® SE7501WV2 SuSE* Linux 8.0 Customer can leverage the Intel certification, if customer Server product meets the operating system vendor standard.
-
Page 11: Adapters And Peripherals
Note that not all adapter cards were tested under all operating systems. The following notation is used in the tested adapters and peripherals table below to indicate the support level that Intel provides for a particular adapter under a particular operating system: This adapter or peripheral has been tested and is supported under the specific Number (i.e. -
Page 12: Pci Raid
Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number PCI RAID Special instructions: SCSI: Bootable device only. SuSE - Must manually select 3Ware driver. ATA: All enabled ATA-RAID Escalade Device BIOS:BE7X 1.08.00.036 3 Ware 7500-8... - Page 13 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: SCSI: Need to enable EDBA Device BIOS:1.62 Device FW: GA0H ASR2010 Adaptec 2010S PCI-64/66 Device Driver Version: Win2K: 5.3.1.3 RedHat 8: Enabled SuSE 8: Enabled NetWare 6:3.1c...
- Page 14 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: SCSI - Need to enable EDBA ATA – W2K All Option ROMs enabled, RedHat – Disable USB legacy Device BIOS:1.62 ASR- Adaptec 3410S PCI-64/66...
- Page 15 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: ATA – All option ROMs enabled Logic Device BIOS:G170 Enterprise Device FW: F316 4714010232 [7], [7], 1600 PCI-64/66 2, 4 6, [7],[9] 2, 4...
- Page 16 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: ATA – All option ROMs enabled Device BIOS:G112 LSI2232 LSI22320- Device FW: 5.07.02 PCI-X133 Device Driver Version: Win2K3:6.36.32 RedHat AS3.0: Enabled SuSE 9: Enabled NetWare 6.5 3.03.03...
- Page 17 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: ATA – All option ROMs enabled Device BIOS:6.08b Device FW: 2.28.06-R04C GDT8623 Device Driver Version: ICP-Vortex GDT8623RZ PCI-64/66 2, 4 2, 4 2, 4 Win2K:3.02...
- Page 18 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: SCSI - Bootable device option ROM enabled only - Have to power drives down every reboot Serial ATA ATA – All option ROMs enabled...
- Page 19 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: SCSI -Bootable device option ROM enabled only ATA – All option ROMs enabled Device BIOS:7.03C 1, 4, Intel SRCU32U Bisbee PCI-64/66 1, 4, 6 1, 4, 6 Device FW: 2.34.00-R030...
- Page 20 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: Device BIOS:7.03C Device FW: 2.34.00-R043 Caldwell Device Driver Version: Intel SRCZCR (Pioneer PCI-64/66 Win2K:1.57 Win2K3: 2, 6 2, 6 2, 6 Square II) Embedded...
-
Page 21: Pci Scsi
Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number PCI SCSI Special instructions: All option ROMs enabled Device BIOS:3.1 Device FW: 3.1 Device Driver Version: ASC- ASC- Win2K: 6.0.4000.200 Adaptec PCI-64/66 2, 4 2, 4... - Page 22 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device BIOS:3.1 Device FW: 3.1 ASC- Adaptec ASC-39160 PCI-64/66 2, 4 2, 4 2, 4 2, 4 Device Driver Version: 39160 Win2K: 6.0.4000.200 RedHat 8:...
-
Page 23: Pci Mromb
Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device BIOS:5.02.00 Device FW: 1.00.14 LSI22320- Device Driver Version: LSI Logic LSI22320-R PCI-X133 2, 5 2, 5 2, 5 2, 5 Win2K: 1.8.16... -
Page 24: Pci Fiber Channel Host Adapters
Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device BIOS:7.03C Caldwell Device FW: 2.34.00-R036 Intel SRCZCR (Pioneer PCI-64/66 Device Driver Version: Square II) Win2K:1.57 RedHat 8: Embedded SuSE 8: Embedded Netware 6: 1.57... - Page 25 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device BIOS: CB1.63A2 Device FW: CS3.90A7 Device Driver Version: Emulex LP9002LP LP9002LP PCI-64/66 Embedded W2K3: ns5-5.01a0cs, NVL: 2.12b, RH3 1.23a...
-
Page 26: Pci Network Interface Cards
Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device BIOS:1.81 Device FW: 1.81 QLA2200 Qlogic QLA2200L PCI-64/66 3, 4, 6 4, 6 Device Driver Version: Win2K: 8.1.5.1 Win2K3: 8.1.5.15 RH 3.0: 6.06.10... - Page 27 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled EtherLink 3C980C- Server Device Driver Version: 3 COM* PCI-32/33 2, 4 2, 4 2, 4 2, 4 10/100 PCI Win2K: 2.0...
- Page 28 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled ATA: Disable USB when installing PRO/1000M RedHat PWLA849 T Gigabit Intel PCI-X133 1, 4 1, 4 1, 4 Device Driver Version:...
- Page 29 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: PRO/1000M All option ROMs enabled T Dual Port Device Driver Version: PWLA849 3, 4, 3, 4, Intel Gigabit PCI-X133 3, 4, 6 Win2K:6.4.16 Win2k3...
-
Page 30: Modems
Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled PRO/1000X Device Driver Version: PWLA849 T Gigabit Intel PCI-X133 Win2K:6.4.16 3, 6 3, 6 3, 6 3, 6 Server RedHat 8: 4.3.15 Adapter SuSE 8: 4.3.15... -
Page 31: Usb/Ps2 Devices
Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled 56K V.92 USR5610 Device Driver Version: 3 COM Performance PCI-32/33 3, 4 3, 4 3, 4 Win2K: 5.22.40.00 RedHat 8: Embedded... - Page 32 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled CRMC- Device Driver Version: CRMC- Mitsumi FX5401W ATA33 2, 4 2, 4 2, 4 2, 4 Win2K: 1.8.16 FX5401W CDROM RedHat 8: Embedded SuSE 8: 2.02.00...
-
Page 33: Dvd Drives
Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device Driver Version: Samsung SC-152 SC-152 ATA33 3, 5 3, 5 3, 5 3, 5 Win2K: Embedded RedHat 8: Embedded... - Page 34 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled DVD- DVD-305S- Pioneer SCSI-N 305S-A Device Driver Version: All Embedded Special instructions: All option ROMs enabled Samsung SD-616 SD-616 ATA33...
-
Page 35: 4.10 Removable Drives
Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number 4.10 Removable Drives Special instructions: All option ROMs enabled MCJ3230 Fujitsu MCJ3230SS SCSI-N Device Driver Version: Win2K: Embedded Special instructions: All option ROMs enabled MCJ3230 Fujitsu... - Page 36 Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled 82-SU- DiskOnKey Device Driver Version: M-systems USB 2.0 3, 5 3, 5 3, 5 128D15 128MB Win2K: Embedded RedHat 8: Embedded...
- Page 37 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device Driver Version: Win2K: Embedded Keytronic Pilot PRO PRO Pilot PS/2 2, 5 2, 5 2, 5 2, 5 RedHat 8: Embedded...
-
Page 38: 4.11 Tape Drives
Adapters and Peripherals Intel® Server Board SE7501WV2 Model Model Manufacturer Interface Comments Name Number 4.11 Tape Drives Special instructions: All option ROMs enabled SCORPION Device Driver Version: STD2401 Seagate 40 DDS4 SCSI-U2 Win2K: Embedded LW-S RedHat 8: Embedded SuSE 8: Embedded... - Page 39 Intel® Server Board SE7501WV2 Adapters and Peripherals Model Model Manufacturer Interface Comments Name Number Special instructions: All option ROMs enabled Device Driver Version: RADEON RADEON PCI-32/33 - 7000 7000 Video W2K3 6.14.10; RH9 embedded Special instructions: All option ROMs enabled...
-
Page 41: Hard Disk Drives
Hard Disk Drives ® The hard drives listed in the following table have been tested with the Intel server board SE7501WV2 by Intel in its validation labs and/or by individual drive vendors. The following operating system identifiers are used in the table to specify which OS each drive was tested under. - Page 42 Note that not all hard drives were tested under all operating systems. The following notation is used in the tested hard drives table below to indicate the support level that Intel provides for a particular hard drive with a particular operating system: This hard drive has been tested and is supported under the operating system identified Number (i.e.
- Page 43 Intel® Server Board SE7501WV2 Hard Disk Drives Drive Tested Manufacturer Product Family Model Number Interface size Operating Comments (GB) Systems Addonics* AEMED35AUM 1, 3, 4, 5, 7, 8, 9 Combo Hard Drive Kit Device FW: 1, 3 Fujitsu* MAN3367MC SCSI-U160-SCA...
- Page 44 Hard Disk Drives Intel® Server Board SE7501WV2 Drive Tested Manufacturer Product Family Model Number Interface size Operating Comments (GB) Systems 128GB of the 185GB on the drive during setup. Fixed in SP3 by adding a registry entry. Hitachi Deskstar 180GXP...
- Page 45 Intel® Server Board SE7501WV2 Hard Disk Drives Drive Tested Manufacturer Product Family Model Number Interface size Operating Comments (GB) Systems Maxtor Atlas 10K III KU036J8 SCSI-U320-SCA 10,000 Maxtor Atlas 10K III KU018J2 SCSI-U320-SCA 10,000 1, 3, 4 Device FW: 020k...
- Page 46 Hard Disk Drives Intel® Server Board SE7501WV2 Drive Tested Manufacturer Product Family Model Number Interface size Operating Comments (GB) Systems Seagate Barracuda ATA V ST340017A ATA/100 7200 Seagate Cheetah* 10K.6 ST3146807LC SCSI-U320-SCA 10,000 1, 3,9 Seagate Cheetah 10K.6 ST373307LC SCSI-U320-SCA...
-
Page 47: Installation Guidelines
“Module FASTTRACK.HAM load status REENT FAIL” Guideline: Disable the on-board Promise driver. Status: Intel is currently working to determine root cause of this issue. SuSE* 8.0 installation hangs while formatting a hard drive on Adaptec ASC39320 Issue: SuSE installation hangs while formatting a hard drive on the Adaptec ASC39320 Implication: The hard drive will not be formatted and the installation of the SuSE 8.0... -
Page 48: Samsung Sp8004H Polaris 40 Hard Drive Jumpers Should Be Removed For Proper Sizing44
Guideline: Use the on-board Adaptec component when formatting hard drives during installation. Status: Intel is currently working to determine root cause of this issue. Samsung SP8004H Polaris 40 hard drive jumpers should be removed for proper sizing Issue: On the SCSI baseboard - When set to a master/slave configuration on the ATA controller, both the system and Windows2000 identifies the slave drive as having 32248MB of space. -
Page 49: Red Hat Linux* 8.0 Segmentation Fault With An Intel® Raid Controller Installed
Issue: When using the normal installation of Red Hat Linux* 8.0 with the 2.4.18-14 kernel and an Intel RAID controller installed, the following issue is seen: 4. A shutdown command results in a segmentation fault. 5. It is not possible to use some tools such as storcon.
