DDS-3 Tape Drive (Optional)
This subsection describes how to remove and replace the optional DDS-3 tape drive.
NOTE The carrier assembly and drive bay may be used for either one DDS-3 tape
drive, or one floppy disk drive.
Removing a DDS-3 Tape Drive:
1. Remove the front panel bezel from the workstation.
2. Remove the two T-15 Torx screws securing the DDS-3 tape drive to the front panel of
the workstation chassis.
3. Slide the DDS-3 tape/floppy disk drive carrier assembly part way out of the chassis
guide rails. Disconnect the the power and ribbon cables from the DDS-3 tape drive.
4. Slide the carrier assembly the rest of the way out of the drive bay.
5. To remove the DDS-3 tape drive from the carrier, remove the four T-10 Torx screws (two
on each side) securing the DDS-3 tape drive to the carrier.
Replacing a DDS-3 Tape Drive:
See the section titled "DDS-3 Tape Drive (Optional) Configuration" on page
NOTE
36 for information about configuring a DDS-3 tape drive for installation.
1. Remove the front panel bezel and the top panel from the workstation.
2. If you are installing a new DDS-3 tape drive into the empty DDS-3 tape/floppy disk
drive bay:
a. Remove the two T-15 Torx screws securing the DDS-3 tape/floppy disk drive carrier
to the front panel of the workstation.
b. Slide the DDS-3 tape/floppy disk drive carrier out of the chassis guide rails.
c. Remove the filler panels from the DDS-3 tape/floppy disk drive carrier as shown in
Figure 4-7 on the next page.
