HP Visualize J5000 - Workstation Handbook page 74

Troubleshooting
Identifying LCD-Indicated Conditions
Table 3-1. Chassis Codes for J5000 and J7000 Workstations
Ostat Code FRU
WRN CB04 SYS BD
WRN CB05 SYS BD
WRN CB0A SYS BD
INI CB0B SYS BD
WRN CB0C SYS BD
WRN CB10 SYS BD
WRN CB11 SYS BD
WRN CB12 SYS BD
WRN CB13 SYS BD
WRN CB14 SYS BD
FLT CB1F SYS BD
WRN CB71 SYS BD
WRN CB72 SYS BD
WRN CB73 SYS BD
CB9 r
FLT IO BD
70
Message
bad OS TOC len
bad OS TOC chksm
prev TOC logged
branch to OS TOC
br OS TOC failed
LPMC initiated
icache LPMC err
dcache LPMC err
dcache tag error
dcache data err
OS LPMC failed
HPMC occurred
LPMC occurred
TOC occurred
Error on rope r
Description
The size of the operating system TOC
handler is invalid. Firmware will soft boot
the system.
The operating system TOC handler failed
the checksum test. Firmware will soft boot
the system.
Firmware detected unread PIM data from
a previous TOC and will not overwrite it.
(PIM for this TOC is lost.)
Branching to the operating system TOC
handler.
Branch to the operating system TOC
handler failed. Firmware will soft boot the
system.
A Low-Priority Machine Check entered
the firmware LPMC handler. The handler
should log the error and return to normal
operation.
An instruction cache parity error caused
the LPMC.
A data cache parity/ECC error caused the
LPMC.
The parity error is in the tag portion of
the data cache.
The parity error is in the data portion of
the data cache.
Firmware couldn't branch to the operating
system LPMC handler. It will halt the
CPU, requiring a power cycle to recover.
A High-Priority Machine Check caused
entry to PDCE_CHECK (the firmware
trap handler).
A Low-Priority Machine Check caused
entry to PDCE_CHECK (the firmware
trap handler).
A Transfer of Control caused entry to
PDCE_CHECK (the firmware trap
handler).
An error was detected on rope r.
Chapter 3
