Product Overview

Personal Computer Type 6832 and 6833 has three
PCI slots and supports the Pentium 4 Willamette
processor family with Socket W processor package
type.
The Personal Computer Type 6832 and 6833
supports Accelerated Graphics Port (AGP) 2X / 4X,
which allows installed system memory to be used as
texture memory, yielding a huge texture footprint to
enhance 3D graphical display performance.
Listed below are 6832 and 6833 system features:

Processor

•
Socket W connector.
•
Detachable CPU fan sink.
•
128 KB of on-chip level one (L1) cache
•
256 KB level two (L2) cache support for Willamette
•
Intel Pentium 4 Williamette processor; 400MHz
front side bus, 1.30/1.40/1.50GHz, Streaming
SIMD Extensions 2 (SSE2) extends MMX
SSE technology
•
Dual channel RDRAM

Memory

•
184-pin Direct Rambus Dynamic Random Access
Memory (DRDRAM), Rambus in-line Memory
Module (RIMM) sockets.
- 4 RIMM sockets.
- 64MB, 128MB and 256MB RIMM.
- PC-133, 2.5V, capable of delivery up to 1.6GB
per second, 8-layer, operating at 800MHz, 16-bit/
serial data output speed with gold contacts
- Maximum memory is 1.5GB
RDRAM
Technology
64MB
128MB
256MB
Increments
16MB
32MB
64MB
Maximum
(2 channels)
512MB
1GB
1.5GB
