Power Supply Output Pin Assignment
Pin
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
+12V Power Connector
1
2
3
4
116
IBM Desktop System HMM
Voltage
Ground
+5Vdc
Ground
Power Good
+5Vdc
+12Vdc
+3.3Vdc
-12Vdc
Ground
+5Vdc
Ground
Ground
Ground
no connect
+5Vdc
+5Vdc
Ground
Ground
+12Vdc
+12Vdc
(Continued)
Cable Color
Black
Red
Black
Gray
Purple
Yellow
Orange
Blue
Black
Green
Black
Black
Black
no connect
Red
Red
Black
Black
Yellow
Yellow
