IBM NetVista Hardware Maintenance Manual page 158

3.5-In Quantum Fireball Series Hard Disk
The configuration of the following jumpers control the
drive's mode of operation:
•
DS - Drive Select (For Master only)
•
CS - Cable Select
•
PK - Park, used as a place to store a jumper
3.5-In Maxtor Hard Disk
3.5-In Maxtor Hard Disk Drive Jumper Settings
J50
On Drive configured as Master or
Drive configured as Master, with an attached
Slave
Off Drive configured as Slave.
126 IBM Desktop System HMM
Description
