Intel Desktop Boards D850MD and D850MV Product Guide

Peripheral Configuration Submenu

Maintenance
This submenu shown in Table 14 is used to enable onboard devices and USB legacy support.
Table 14.

Peripheral Configuration Submenu

Feature
Serial Port A
Base I/O address
(This feature is displayed
only if Serial Port A is set
to Enabled.)
Interrupt
(This feature is displayed
only if Serial Port A is set
to Enabled.)
Serial Port B
Base I/O address
(This feature is displayed
only if Serial Port B is set
to Enabled.)
Interrupt
(This feature is displayed
only if Serial Port A is set
to Enabled.)
54
Main
Advanced
PCI Configuration
Boot Configuration
Peripheral Configuration
IDE Configuration
Diskette Configuration
Event Log Configuration
Video Configuration
Options
• Disabled
• Enabled
• Auto (default)
• 3F8 (default)
• 2F8
• 3E8
• 2E8
• IRQ 3
• IRQ 4 (default)
• Disabled
• Enabled
• Auto (default)
• 3F8
• 2F8 (default)
• 3E8
• 2E8
• IRQ 3 (default)
• IRQ 4
Security Power
Description
Configures serial port A.
Auto assigns the first free COM port, normally COM 1, the
address 3F8h, and the interrupt IRQ4.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
Specifies the base I/O address for serial port A, if serial
port A is set to Enabled.
Specifies the interrupt for serial port A, if serial port A is
set to Enabled.
Configures serial port B.
Auto assigns the first free COM port, normally COM 2, the
address 3F8h, and the interrupt IRQ4.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
Specifies the base I/O address for serial port B, if serial
port B is set to Enabled.
Specifies the interrupt for serial port B, if serial port B is
set to Enabled.
Boot Exit
continued
