Chapter 10
Alarm Monitoring and Management
Procedure: Apply an Alarm Profile at the Card View
Step 1
In CTC, display the card view of the desired card.
Step 2
Click the Provisioning > Alarm Behavior tabs.
To apply profiles on a port-to-port basis:
Step 3
a.
b.
c.
To set a profile for all the ports on a card:
Step 4
a.
b.
c.
d.
Tip
If you choose the wrong profile, click Reset to return to the previous profile setting.
Procedure: Apply an Alarm Profile at the Node View
In CTC, display the node view.
Step 1
Click the Provisioning > Alarm Profiles tabs.
Step 2
Step 3
To apply profiles on a card basis:
a.
b.
c.
Step 4
To apply the profile to an entire node:
a.
b.
c.
Note
Tip
If you choose the wrong profile, click Reset to return to the previous profile.
November 2001
Click the appropriate row under the Profile column for the port desired.
Choose the appropriate Profile.
Click Apply. (Multiple port profiles can be selected before clicking Apply.)
Click the Force all ports to profile menu arrow at the bottom of the screen.
Choose the appropriate Profile.
Click Force (still need to "Apply")
Click Apply.
Click the Profile column for the card desired.
Choose the appropriate Profile.
Click Apply. (Multiple card profiles can be selected before clicking Apply.)
Click the Node Profile menu arrow.
Choose the appropriate Profile.
Click Apply.
The Port Overrides column at the node view reads true when additional profiles are available
and false when only the inherited profile is available.
Cisco ONS 15454 Installation and Operations Guide
Alarm Profiles
10-13
