Chapter 7 Card Provisioning
Note If the DS3E is installed in an ONS 15454 slot that is provisioned for a DS-3 card, the DS3E enhanced
performance monitoring parameters are not available. If this occurs, remove the DS3E from the ONS
15454, delete the DS-3 card in CTC, and provision the slot for the DS3E.

Procedure: Modify Line and Threshold Settings for the DS3E Card

Step 1 Display the DS3E-12 or DS3EN-12 in CTC card view.
Step 2 Click the Provisioning tab.
Step 3 Depending on the setting you need to modify, click the Line, Line Thrshld, Elect Path, or Sonet
Thrshld subtab.
Note
Step 4 Modify the settings shown in
For numerics, double-click the field and type the new number.
Table 7-4
Subtab
Line
November 2001
See Chapter 10, "Alarm Monitoring and Management"
Behavior tab.
Table 7-4 on page
DS3E Card Parameters
Parameter Description
Port # Port number
Port Port name
Line Type Defines the line framing type
Detected Displays the detected line type
Line Type
Line Defines the DS3E transmission
Coding coding type
Line Defines the distance (in feet)
Length from backplane connection to
the next termination point
Status Places port in or out of service
for information about the Alarm
7-9. For drop-down lists, select an item from the list.
Options
1 - 12
•
To enter a name for the port, click the
cell and type the name. To change a
name, double-click the cell, then edit
the text.
M23
•
• C Bit
Auto Provisioned
•
Read-only
• B3ZS
• 0 - 225 (default)
• 226 - 450
Out of Service (default)
In Service
Cisco ONS 15454 Installation and Operations Guide
Provisioning Electrical Cards
7-9
