Chapter 1 Hardware Installation

Figure 1-43 Attaching ferrites to SMB/BNC connectors

Procedure: Attach Ferrites to Wire-Wrap Pin Fields

Use an oval ferrite TDK ZCAT1730-0730 and block ferrite Fair Rite 0443164151 for each pair of cables.
Figure 1-44
Wrap the cables once around and through the block ferrites and pull the cables straight through the oval
Step 1
ferrites.
Place the oval ferrite as close to the wire-wrap pin field as possible and between the ONS 15454 and the
Step 2
block ferrite as shown. The block ferrite should be within 5 to 6 inches of the wire-wrap pin field.

Figure 1-44 Attaching ferrites to wire-wrap pin fields

November 2001
B
shows the suggested method for attaching ferrites to wire-wrap pin fields.
B
A
A
Cisco ONS 15454 Installation and Operations Guide
Ferrite Installation
1-63
