Chapter 8
Performance Monitoring
Table 8-28 Far-End VT PMs for the DS3XM-6 Card
Parameter
CV-V
ES-V
SES-V
UAS-V
8.6 Performance Monitoring for Optical Cards
The following sections define performance monitoring parameters and definitions for the OC-3, OC-12,
OC-48, and OC-192.
8.6.1 OC-3 Card Performance Monitoring Parameters
Figure 8-21
parameters for the OC-3 card.
November 2001
Definition
Code Violation VT Layer (CV-V) is a count of the BIP errors detected at
the VT path layer. Up to two BIP errors can be detected per VT
superframe; each error increments the current CV-V second register.
Errored Seconds VT Layer (ES-V) is a count of the seconds when at least
one VT Path BIP error was detected. An AIS-V defect (or a lower-layer,
traffic-related, near-end defect) or an LOP-V defect can also cause an
ES-V.
Severely Errored Seconds VT Layer (SES-V) is a count of seconds when
K (600) or more VT Path BIP errors were detected. An AIS-V defect (or
a lower-layer, traffic-related, near-end defect) or an LOP-V defect can
also cause an SES-V.
Unavailable Second VT Layer (UAS-V) is a count of the seconds when
the VT path was unavailable. A VT path becomes unavailable when ten
consecutive seconds occur that qualify as SES-Vs and continues to be
unavailable until ten consecutive seconds occur that do not qualify as
SES-Vs.
shows where overhead bytes detected on the ASICs produce performance monitoring
Performance Monitoring for Optical Cards
Cisco ONS 15454 Installation and Operations Guide
8-33
