Editing Mio Modero DMS and DMS Pinnacle Button Properties
With a project file open in KeypadBuilder:
1. Click on the button in the Page Navigation Window to select it.
2. Go to Project > Button Item Properties to launch the Button Properties Dialog Window.
3. Once done making changes, click OK.
Working with List boxes
A Static List box Table
A static list box populates button information based on data stored on the Mio Modero DMS. The device
cannot display current state information provided by the master like A Dynamic List box Table can.
Conversely, the device will resume the last known static table event should power be cycled.
A Dynamic List box Table
A dynamic list box table populates button information base upon communications between the Mio
Modero DMS and a master. Opposed to static tables, the information displayed on the device is passed
through the master to the device. Dynamic tables are great for creating parameters for displaying
changing options, i.e., date, time or temperature; however, if the device loses power it will not be able to
display the last known states. After creating a dynamic table, Specify Channel Allocation and Specify
Port Allocation.
Creating a List box Table
Now that the list box has been allocated for on the keypad page, navigation buttons have been set for the
list box and properties have been established for the list box it is time to create A Static List box Table.
1. Select the list box button in the Page Navigation Window.
2. Go to Project > List box Items... to launch the Associate Data Table Dialog Window.
3. Click the radio button next to Create New Table.
4. In the space provided, type a unique name for the table.
5. Assign a Port and Address for the table. See Working With Function Codes for more information on
Ports and Addresses.
6. Click OK to confirm and launch Edit List Table Dialog Window.
7. Click the New button to launch the Add/Edit List-box Items Dialog Window.
8. Note the font information is fixed to what was set in the List box Button Properties Dialog Window.
Type the information to be displayed in the list box table cell in the field Caption.
9. Click the drop down menu for page flip if you want to set the item in this cell as a page flip button.
The drop down list is populated with pages already created in the keypad project file.
10. Assign any Port and Channel information. See Working With Function Codes for more information.
11. Click OK
12. Repeat for as many items as needed.
13. Click OK.
Congratulations, you now have a list box button, with navigation, and a list box to display on the keypad.
Working with List boxes
List boxes provide flexibility to keypad pages once constrained by physical display areas. Both static and
dynamic tables can display multiple devices and items when used with proper navigation tools.
KeypadBuilder v2.1
Mio Modero DMS Application Operations
99
