Audio Input Connectors:
Impedance:
Levels:
CMRR:
Audio Output Connectors:
Impedance:
Levels:
Protection:
A/D Performance Frequency
Response:
Crosstalk:
S/N Ratio:
THD:
Dynamic
Range:
Delay:
D/A Performance Frequency
Response:
Crosstalk:
S/N Ratio:
THD:
Dynamic
Range:
Delay:
A/A Performance Frequency
Response:
Crosstalk:
S/N Ratio:
THD:
Dynamic
Range:
Combined 3 pole XLR and 1/4 inch T/R/S phone jacks (2)
0 dB/BAL switch position: 100k , balanced
-20 dB/UNBAL switch position: 50k , unbalanced
0 dB/BAL switch position: -2 dBu min for full scale, +20 dBu max
-20 dB/UNBAL switch position: -22 dBu min for full scale, 0 dBu max
0 dB/BAL switch position: 50 dB minimum, 10 Hz to 20 kHz
1/4 inch T/R/S phone jacks (2); balanced XLRs, pin 2 "high" (2)
100 , balanced
+18 dBm, full scale (+4 dBu setting) balanced, unbalanced
+4 dBm, full scale (-10 dBu setting)
Relays provided for output muting during power on/off
10 Hz to 20 kHz, ±0.5 dB
<-65 dB, 10 Hz to 20 kHz
>102 dB, 20 kHz bandwidth
<0.003% max, 10 Hz to 20 kHz
>102 dB, 20 kHz bandwidth
24 samples (0.54 msec for 44.1 kHz, 0.50 msec for 48 kHz)
10 Hz to 20 kHz, ±0.5 dB
<-80 dB, 10 Hz to 20 kHz
>98 dB, 20 kHz bandwidth
<0.005%, 10 Hz to 20 kHz
>98 dB, 20 kHz bandwidth
50 samples (1.13 msec for 44.1 kHz, 1.04 msec for 48 kHz)
10 Hz to 20 kHz, ±0.5 dB
<-55 dB, 10 Hz to 20 kHz
>96 dB, 20 kHz bandwidth
<0.005%, 10 Hz to 20 kHz
>96 dB, 20 kHz bandwidth

Specifications

7
PCM 81
Specifications
7-1
