2-16 Setup and Operation
Use the legend keys to make the selections and exit to the Main Menu. Use Table 2-8 to
configure the peripherals.
Table 2-8 Integrated Peripherals Parameters
Feature
COM A Port
COM B Port
LPT Port
LPT Mode
ECP Channel
Diskette Controller
Local Bus IDE
Controller
PS/2 Mouse
On-board Sound
Options
Disabled
User-selectable settings
Auto
Disabled
378, IRQ 7 (default)
User-selectable settings
Auto
Output only (default)
Bi-directional
ECP
DMA 0
DMA 1
DMA 3
Enabled (default)
Disabled
Both (default)
Primary
Disabled
Enabled (default)
Disabled
Stereo with SRS
(default)
Stereo
Description
Selects a unique address and interrupt request
for the listed COM ports. Auto selects the next
available combination.
Factory settings:
COM A port default: 3F8, IRQ 4
COM B port default: 2F8, IRQ 3
Selects a unique address and interrupt request
for the LPT port. Auto selects the next available
combination.
Enables parallel port to function normally
(Output only), bidirectional, or in an enhanced
capabilities port (ECP) mode. Check the printer
documentation to set the correct LPT mode for
your printer.
Available when ECP is selected for the LPT
mode.
Enables the on-board diskette drive controller.
Enables the on-board IDE controllers. "Both"
enables the primary (fast) and secondary
(standard) channels. The "Primary" option
enables only the primary (fast) channel
Enables/disables the PS/2-style mouse.
This parameter is only available when the BIOS
detects integrated audio on the system board.
When the audio is detected, stereo with surround
sound is the default.
If playing an audio file with SRS built-in, use the
Stereo setting.
