protrude above the equipment case.
This will prevent dropouts due to
shadow effects of the case.
5 Cleaning
To clean the transmitter case,
use a soft cloth moistened with
water.
18

6 Specifications

Receiving frequency range: 710 to
865 MHz
Modulation: FM
Audio bandwidth: 40 to 20,000 Hz
T.H.D.: <0.8%
Signal/noise ratio: 108 dB(A) typ.
Current consumption: 120 mA typ.
Battery life: >6 hours (2 x 1.5 V
AAA size batteries)
Audio outputs: Unbal. line (tip): -6
dBm (10 k )
Headphone output
(ring): 18 mW typ. into
15 ; 13 mW typ. into
100
Size: 77 x 55 x 15 mm
(3 x 2.2 x 0.6 in.)
Weight: approx. 60 g (2.1 oz.)
This product complies with the following
standards: EN60065:1998, EN301 489-9
v.1.1.1 (09-2000) and EN300 422-2 v.1.1.1
(07-2000).
