Chapter 3 Installing the Cisco VG224 Voice Gateway

Connecting a UPS to an AC-Powered Cisco VG224

Connect an uninterruptible power supply to the AC input on your Cisco VG224 voice gateway. Before
you install a UPS, be sure to read the installation instructions for the UPS.
Figure 3-17
Note Figure 3-17
Figure 3-17 Connecting a UPS to an AC-Powered Cisco VG224
AC wall plug
OL-5006-04
shows a setup using a UPS.
shows one possible setup; please review your UPS documents before setting up your system.
UPS
Cisco VG224 voice gateway
VG2 24- 24F
XS
AC plug
Cisco VG224 Voice Gateway Hardware Installation Guide
Connecting Backup Power
3-23
