Paper Jams In The Rear Cover Or Duplex Unit (Mf8350Cdn Only) - Canon Color imageCLASS MF8050Cn Basic Operation Manual

4
Lower the manual feed transport guide.
(1) Hold the tabs (A) on both sides.
(2) Push them down.
5
Remove the paper by pulling it gently.
6
Return the manual feed transport guide to its
original position.
7
Close the manual feed slot cover.
8
Insert the paper cassette into the machine.
9
When the following screen appears, select <Yes>
with [ ], and then press [OK].
The machine is ready to print.
Is all of the jammed
paper removed?
Yes
9-6
(A)
No
Paper Jams in the Rear Cover or Duplex Unit
(MF8350Cdn Only)
Referring to the procedure on the display, follow the steps
below to remove jammed documents.
Keys to be used for this operation
1
Press [ ].
Paper jam.
Press [ ] to
display steps.
2
Open the rear cover.
(1)
(2)
3
Open the paper output guide by holding the
green tab (A).
(A)
