After checking the cursor position at the upper left of Ladder Window, start programming.
C
0 of the upper
0 digit of an
address can
be omitted.
ENT
Switch 1
ENT
0 of the upper digit of an address is omitted when shown.
[.] (period) is displayed between a channel number and a relay number.
Opening a
Opening a
new project
new project

5-1. Entry of Normally Open Contact

Press [C] from a keyboard to open the [New Contact] dialog.
Device type
Device type
settings
settings
Enter a symbol
comment.
Deletion of instructions
Move the cursor to the instruction
and then press the DEL key.
Move the cursor to the right cell of
the instruction and press the BS key.
Creating a
Creating a
program
program
