Omron CX-PROGRAMMER - INTRODUCTION GUIDE Introduction Manual page 45

Online
Online
to Transfer
to Transfer
Double-click the mouse.
An entry dialog
opens.
Enter a new
value that you
want to change to.
4-word data is
4-word data is
displayed in the
displayed in the
binary system.
binary system.
As shown in the guidance at
the bottom of the dialog,
Force On/Off and Set On/Off
are enabled also by key
operation.
Monitoring
Monitoring
7. Monitoring - 5
Present Value Change and Binary Monitoring in Watch Window
The present values of bits and words are changed in Watch Window.
In Watch Window, binary monitoring is possible for the data that can be
treated by the word.
Force On
Force On
Force Off
Force Off
Program
Program
Check
Check
Click
Click the right mouse button
on a bit, and you will be able
to select Force On/Off and
Set On/Off from the popup
menu.
Online
Online
Edit
Edit
