Entry Of Coil - Omron CX-PROGRAMMER - INTRODUCTION GUIDE Introduction Manual

Installation
Installation
to Startup
to Startup
O
100
ENT
Coil 0
ENT
Press [R] to normalize a rung.
R
Useful Function: Automatic check of duplicated coils
Useful Function: Automatic check of duplicated coils
If a duplicated coil is entered during program creation, the following message is
If a duplicated coil is entered during program creation, the following message is
displayed and you can notice that the coil is duplicated right away.
displayed and you can notice that the coil is duplicated right away.
Double-click by using a mouse (or press F4). The cursor
moves to the place of the applicable coil on Ladder Window.
The place of a duplicated coil in the program is displayed.
Opening a
Opening a
new project
new project

5-2. Entry of Coil

Press [O] from a keyboard to open the [New Coil] dialog.
Output Window
automatically opens.
Device type
Device type
settings
settings
Rungs are also normalized when you move the
cursor position to the cell inverted in blue by
pressing the arrow keys from a keyboard or
using a mouse.
Press the [ESC] key to close
the open Output Window.
Double-click
Double-click
Creating a
Creating a
program
program
