Installation Instructions
Tracer Concierge
Small Buildings
Pre-Packaged Control Panel and Display
Model Numbers:
Only qualified personnel should install and service the equipment. The installation,
starting up, and servicing of heating, ventilating, and air-conditioning equipment
can be hazardous and requires specific knowledge and training. Improperly
installed, adjusted or altered equipment by an unqualified person could result in
death or serious injury. When working on the equipment, observe all precautions in
the literature and on the tags, stickers, and labels that are attached to the
equipment.
December 2023
BMTC015ABC012000
BMTC030ABC012000
BMTC060ABC012000
SAFETY WARNING
BAS-SVN141E-EN
®
System for
BMTC030ABC000000
BMTC030ABC002100
BMTC060ABC002100
