The page includes the following fields:
Object
• ID
• Interval
• Variable
• Sample Type
• Value
• Startup Alarm
• Rising Threshold
• Rising Index
• Falling Threshold
• Falling Index
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Updates the table, starting from the first entry in the Alarm Table, i.e. the entry with the lowest ID.
: Updates the table, starting with the entry after the last entry currently displayed.

4.2.3.3 RMON Event Configuration

Configure RMON Event table on this page. The entry index key is ID; screen in
User's Manual of GS-5220 LCD Series Managed Switch
Figure 4-2-3-2: RMON Alarm Overview Page Screenshot
Description
Indicates the index of Alarm control entry.
Indicates the interval in seconds for sampling and comparing the rising and
falling threshold.
Indicates the particular variable to be sampled.
The method of sampling the selected variable and calculating the value to be
compared against the thresholds.
The value of the statistic during the last sampling period.
The alarm that may be sent when this entry is first set to valid.
Rising threshold value
Rising event index
Falling threshold value
Falling event index
105
Figure 4-2-3-3 appears.
