W
ORK
M
ONITOR
D
EPLOYMENT
Use and Disclosure of Data Information contained herein is classified as EAR99 under the U.S. Export
Administration Regulations. Export, reexport or diversion contrary to U.S. law is prohibited.
H
ORSE
/ S
ENTINEL
G
UIDE
P/N 957-6285-00 (July 2023)
© 2023 Teledyne RD Instruments, Inc. All rights reserved.
https://www.teledynemarine.com
Advertisement
Related Manuals for Teledyne WORKHORSE
Summary of Contents for Teledyne WORKHORSE
- Page 1 EPLOYMENT UIDE P/N 957-6285-00 (July 2023) © 2023 Teledyne RD Instruments, Inc. All rights reserved. https://www.teledynemarine.com Use and Disclosure of Data Information contained herein is classified as EAR99 under the U.S. Export Administration Regulations. Export, reexport or diversion contrary to U.S. law is prohibited.
-
Page 2: Table Of Contents
(this can take up to 24 hours). Once you have secured an account, use the Teledyne Marine software portal to access this data with your unique username and password. -
Page 3: Workhorse And Workhorse Ii
P/N 957-6285-00 (July 2023) Workhorse and Workhorse II This guide covers the original Workhorse (WH) system and Workhorse II (WHII) 6000-meter systems which include the LPMBH 7-pin connector. Repaired systems that require a PC board replacement shipped after November 2022 will ship with the WHII electronics and the WH LPMBH 7-pin end-cap connector. -
Page 4: Preparing The Adcp
Connect the battery and seal the WorkHorse ADCP before deployment. 977-6013-00 Memory (Sentinel only) The WorkHorse Sentinel ADCP includes one memory card installed inside the system. Two PCMCIA memory card slots are available. Workhorse II Sentinel ADCPs come standard with one CompactFlash memory card with maximum memory capacity not to exceed 4GB. - Page 5 Desiccant, Sealed Bag 817-1067-00 Screw, Pressure Sensor Pressure Sensor For high pressure systems, see the WorkHorse Operation Manual, Chapter 4 for a list of the included tools and spare parts. Page 3 EAR99 Technology Subject to Restrictions Contained on the Cover Page.
- Page 6 3. Use our online customer portal at to download manuals or other Teledyne RDI documentation. Download the Workhorse Operation Manual Guide and the Commands and Output Data Format guide. PDF versions of all Workhorse documentation are available for download. Workhorse Operation Manual Guide...
- Page 7 Tighten the bolts to the recommended torque value of 5.6 Newton-meters (50 pound-inches). For high pressure systems, see the WorkHorse Operation Manual, Chapter 4 for instructions on end-cap replacement. Page 5 EAR99 Technology Subject to Restrictions Contained on the Cover Page.
- Page 8 Check that the system is closed properly. For more information about installing the battery and system close-up, see chapter 4 in the WorkHorse Operation Manual. Page 6 EAR99 Technology Subject to Restrictions Contained on the Cover Page.
-
Page 9: Connecting To The Adcp
All Rights Reserved. All Rights Reserved. > > The system has the Workhorse II electronics in- The system has the original Workhorse electronics stalled. Use the Workhorse II Plan software to installed. Use the PlanADCP software to create a create a deployment command file. - Page 10 ADCP. >{¡┐φ²∩╜╜²²jñ~ªñδgJ Checking 9600 baud rate Checking 115200 baud rate WorkHorse II Broadband ADCP Version 7x.xx Teledyne RD Instruments (c) 1996-2022 All Rights Reserved. > If you don’t know what com port(s) were added when using a USB to serial adapter, use Windows Device Manager ®...
-
Page 11: Planning The Deployment
E P L O Y M E N T I N C L U D E S T H E F O L L O W I N G S T E P S Creating a command file using PlanADCP or Workhorse II Plan Use the PlanADCP software to create a de- ployment command file for a system that has the original Workhorse electronics. - Page 12 WorkHorse Monitor/Sentinel Deployment Guide P/N 957-6285-00 (July 2023) Quick Review Check that the resources for the Use the PlanADCP or Workhorse II Plan deployment are acceptable. software to verify all consequences. Use the Workhorse II Plan software to create a deployment command file for a system with WHII electronics.
-
Page 13: Deploying The Adcp
TRDI Toolz has a user-friendly interface for running the pre-deployment tests and setting the Moni- tor/Sentinel real-time clock. Refer to the Workhorse and Workhorse II Command Guide for a listing of all direct commands and their format. Setting the ADCP Clock The real-time clock (date and time) within the Monitor/Sentinel maintains the correct time while system power is removed. - Page 14 If the Depth sensor is not zero, zero the pressure sensor. 5. If a sensor fails, contact TRDI Field Service. See the WorkHorse Operation Manual, Chapter 5 for details on testing the sensors. Page 12 EAR99 Technology Subject to Restrictions Contained on the Cover Page.
- Page 15 With a large variety of instrument orientations (ideally tilting the instrument by 30 degrees or more during orientation). • TRDI recommends that if you are having trouble calibrating the Workhorse II ADCP compass that you move the system and/or ensure the area around the system is clear of electrical equipment and ferrous materials.
- Page 16 Communication errors may occur during calibration when using a slow communication Baud rate. If you receive a Failed to get calibration data… message, try increasing the Baud rate (115200 Baud is recommended). The Workhorse II uses a Hard break. 3. Click the Calibrate button.
- Page 17 Help. e. Quit. 5. Tilt the ADCP. Tilt an upward-looking WorkHorse with a block under one side of the end-cap. A 35-mm block will give you an 11-degree tilt. Check the on-screen instructions to see if the orienta- tion is OK. Adjust as necessary.
- Page 18 You MUST remove the cover to collect good data. Deploying the ADCP Planning the Use TRDI’s software PlanADCP or Workhorse II Plan to create and save a command file (see Deployment). To send multiple commands to configure the ADCP and start it pinging: 1.
- Page 19 Send the command file to the ADCP You MUST remove the transducer cover to collect good data. Read Chapter 2 in the Workhorse Operation Manual for information on how to install/mount the ADCP for a deployment. Page 17...
-
Page 20: Recovering Data
Compass Post Calibration corrects for heading errors due to hard and soft iron effects in the Workhorse reference frame during the deployment. Often, post calibration will provide results more reliable than when only a pre-deployment calibration is performed. - Page 21 WorkHorse Monitor/Sentinel Deployment Guide P/N 957-6285-00 (July 2023) To post calibrate the data: 1. Use TRDI Toolz to download the data from the CompactFlash recorder. For example, the pd0 data file is named _RDI_000.000 and the _RDI_000.cal is the post calibration file and both files are down- loaded to the same folder.
- Page 22 PD0 data formats that are commonly output by Teledyne Marine/Teledyne RD Instruments ADCPs. The definition and details of the PD0 format can be found in the Workhorse II Commands and Output Data Format guide. Available for download from the Teledyne Marine software portal: https://tm-portal.force.com/TMsoftwareportal.
- Page 23 WorkHorse Monitor/Sentinel Deployment Guide P/N 957-6285-00 (July 2023) Quick Review Download the data. Use TRDI Toolz to download data. Post-calibrate the compass data for WHII Use Compass Post Calibration software. systems Check and process the data Read the WinADCP help file for information on how to check and process data.
-
Page 24: Conclusion
P/N 957-6285-00 (July 2023) Conclusion Congratulations! You have completed the Monitor/Sentinel Self-Contained Deployment Guide. Read the following chapters in the Workhorse Operation Manual for more detailed information. WorkHorse Operation Manual Chapter 1 – At a Glance This chapter includes an overview of the Monitor/Sentinel features, options, computer, power, software requirements, and connecting to the Monitor/Sentinel ADCP.
