Chapter 6: Installation
SeaTalk
The SeaTalk standard was originally developed by Autohelm (part of the
Raytheon group), and allows compatible instruments to be connected by
a single cable carrying power and data in/out. This means that additional
instruments and functions can be added to a SeaTalk system, simply by
plugging them into the network.
SeaTalk is a precise, high-speed, bi-directional protocol which is flexible
enough to adapt to any number of instrument heads, without a central
processor. SeaTalk equipment can also communicate with non-SeaTalk
equipment via the NMEA standard.
Scanner
GPS
SeaTalk
Integrated System with Repeater Display and SeaTalk Instruments
HSB Series Display
SeaTalk
SeaTalk
Course Computer
SeaTalk
HSB Series Display
HSB
Distribution Panel
12/24V Supply
12/24V Supply
12/24V Supply
101
D4289-1
