Using Route Information to Review Your Passage Plan

You can view data for all the waypoints in the current route, or any saved
route.
You select the route from the database list and the information is
displayed in a Route Information pop-up; the following details are
provided for each waypoint:
Position
Bearing (from previous waypoint)
Length of leg (from previous waypoint)
Total Length
Time (ETA or Elapsed)
Soft keys are provided to toggle the time between ETA or elapsed and to
change the Speed Over Ground (SOG) value; the ETA for each
waypoint is calculated using the selected SOG, so you can change the
SOG to determine its effect on your ETA.
The Review Your Passage Plan scenario in Chapter 2 provides a simple
example of how to use the route information.
To display information about any route in the database:
1. Press the ROUTE soft key, followed by MORE, then press ROUTE
ROUTE
LIST
LIST. The route list is displayed. The grey selection bar indiates the
selected route.
2. Use the trackpad to select the required route, then press the ROUTE
ROUTE
INFO
INFO soft key.
The Route Information pop-up is displayed, listing the waypoints in
the route and detailing bearing, length of each leg, total distance, and
either the estimated time of arrival (ETA) or the elapsed time.
The soft keys allow you to toggle between ETA or total (elapsed)
time, and to change the Speed Over Ground (SOG) value used in
the time calculations. The current selections are highlighted.
To change the SOG used for ETA calculations:
1. Press one of the PLANNED SOG keys to switch from actual to
planned SOG.
2. Press the up or down PLANNED SOG keys to change the planned
SOG value. The Time values in the Route Information list are
updated.
3. Press the ACTUAL SOG key to use the actual SOG value rather
than a planned one.
