52
3. Move the cursor to the position on the chart where you want your first
PLACE
WAYPOINT
waypoint to be. Press the PLACE WAYPOINT softkey.
Note: You can position the cursor on an existing waypoint, if required
– the text WPT indicates you are re-using the waypoint rather than
placing a new one. This waypoint is included in the route when you
press PLACE WAYPOINT.
The waypoint appears on the screen at the cursor position. The
number displayed alongside the waypoint identifies its position in the
route. The new waypoint is temporarily added to the waypoint list
with the first available waypoint number. The waypoints in the current
route are re-numbered to identify the new positions.
Note: if you Clear the route before it is Saved, the waypoint is
removed.
4. Move the cursor to the next waypoint position. A dotted line connects
the cursor to the last placed waypoint.
PLACE
5. Press PLACE WAYPOINT again. The waypoint is placed and the
WAYPOINT
dotted line changes to a solid line.
If you placed the waypoint incorrectly, you can delete the last-placed
UNDO
waypoint by pressing the UNDO WAYPOINT soft key.
WAYPOINT
6. Repeat steps 4 and 5 until you have placed all your waypoints. You
can have up to 50 waypoints in a route.
7. When you have entered all your waypoints, either :
Press the ACCEPT soft key (or ENTER) to complete the route. Your
ACCEPT
ROUTE
route is displayed on the screen, and is the current route, but it is not
active.
The first waypoint of a new route is outlined with a square, indicating
that it will be the target waypoint when the route is activated. If
selected, the waypoint data box is displayed for the target waypoint.
8. Press the MORE soft key to access the SAVE ROUTE function, or
ENTER to return to the default display.
Note: The completed route is stored in the display unit, and will be re-
displayed if you turn the unit off and on again. However, on an integrated
system it is possible for a current route from another unit to overwrite this
route; it is recommended that you Save the route as described.
HSB Series Chartplotter
