EXPLORER
500
™
USER MANUAL
Thrane & Thrane A/S • info@thrane.com • www.thrane.com

Advertisement

Table of Contents
loading

Related Manuals for Inmarsat EXPLORER 500

Summary of Contents for Inmarsat EXPLORER 500

  • Page 1 EXPLORER ™ USER MANUAL Thrane & Thrane A/S • info@thrane.com • www.thrane.com...
  • Page 2 Windows and Outlook are registered trademarks of Microsoft Corporation in the United States and other countries. • Inmarsat is a registered trademark of the International Maritime Satellite Organisation (IMSO) and is licensed by IMSO to Inmarsat Limited and Inmarsat Ventures plc. •...
  • Page 3 This device emits radio frequency energy when switched on. To avoid injury, keep a minimum safety distance of 0.6 m from the antenna front when the EXPLORER 500 is on. See also the below section Antenna safety instructions. Only use approved batteries from Thrane & Thrane Use of non approved batteries may result in explosion, fire, electrical shock or injury.

  • Page 4: Antenna Safety Instructions

    Antenna safety instructions Antenna safety instructions Use only manufacturer supplied antennas Antenna minimum safe distance: 60 cm Antenna gain Directional, with maximum gain of 11.1 dB reference to isotropic. The Federal Communications Commission has adopted a safety standard for human exposure to RF (Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits.

  • Page 5: About This Manual

    Intended readers This manual is a user manual for the EXPLORER 500. The readers of the manual include anyone who is using or intends to use the EXPLORER 500. No specific skills are required to operate the EXPLORER 500. However,...

  • Page 6: Table Of Contents

    Table of Contents Safety summary ....................iii Antenna safety instructions .................. iv About this manual ....................v Chapter 1 Introduction Welcome ........................1 In this chapter ......................1 The BGAN system ....................2 The BGAN services ....................4 Features and interfaces of the EXPLORER™ 500 ............5 Your EXPLORER™...
  • Page 7 Table of Contents Navigating the display and keypad ..............35 The menus ......................36 Messages menu ....................37 Connect menu ..................... 38 Calls menu ......................39 Settings menu ..................... 40 Properties menu ....................43 Help desk ......................45 Dynamic information in the display ..............46 What’s next? ......................
  • Page 8 Table of Contents Additional interfaces ..................73 Using an external antenna .................. 73 Using the EXPLORER™ Bluetooth Handset charger ..........73 What’s next? ...................... 74 Chapter 5 Using the web interface In this chapter ....................75 Introduction ....................... 75 The web interface ....................75 Accessing and navigating the web interface ............
  • Page 9 Table of Contents Turning audio indicators on or off ............... 95 Enabling activation of stealth mode ..............95 Setting up the interfaces .................. 96 Enabling/disabling interfaces ................96 Description of data settings ................. 96 Configuring the USB interface ................98 Configuring the LAN interface ................100 Configuring the Bluetooth interface ..............104 Pairing Bluetooth devices from the web interface ..........107...
  • Page 10 Table of Contents Appendix A Technical specifications In this appendix ....................151 General specifications ..................151 Battery ....................... 152 Power input ......................153 SIM interface ...................... 153 Phone/Fax interface ................... 154 LAN interface ......................155 USB interface .....................156 Bluetooth interface ..................... 157 Built-in antenna ....................158 External antenna ....................159 EXPLORER™...

  • Page 11: Chapter 1 Introduction

    Just plug in a phone, fax, laptop or PDA, or use the Bluetooth® interface, point the antenna towards the BGAN satellite - and you are online. The flat, light-weight design of the EXPLORER 500 makes it easy to carry e.g. in the front pocket of a laptop bag.

  • Page 12: The Bgan System

    Internet, transfer files and make telephone calls. Coverage The Inmarsat® BGAN services are based on geostationary satellites situated above the equator. Each satellite covers a certain area (footprint). The coverage map below shows the footprints of the BGAN system.
  • Page 13 A complete BGAN system may include the EXPLORER 500 with connected peripherals, the BGAN satellite, and the Satellite Access Station (SAS). The satellites are the connection between your EXPLORER 500 and the SAS, which is the gateway to the worldwide networks (Internet, telephone network, cellular network, etc.).

  • Page 14: The Bgan Services

    Chapter 1: Introduction The BGAN services Supported services The services currently supported by BGAN comprise: • A Packet Switched connection to the Internet • A Circuit Switched (Dialed) connection for voice, fax or data • Short Messaging Service (SMS) Packet data service The BGAN network supports different classes of data connection to the Internet.

  • Page 15: Features And Interfaces Of The Explorer™ 500

    Chapter 1: Introduction Features and interfaces of the EXPLORER™ 500 Features The EXPLORER 500 provides the following features: High speed data up to 464 kbps - shared bandwidth Support for Streaming classes 32, 64 and 128 kbps Simultaneous voice and data...
  • Page 16 Chapter 1: Introduction Overview of interfaces The EXPLORER 500 provides a number of interfaces for connection of various types of computers, fax devices and phones. Bluetooth Bluetooth Handset USB or LAN USB or LAN Standard Phone Standard Phone Connection Connection Using the interfaces on page 48 describes how to use each of the available interfaces.

  • Page 17: Your Explorer™ 500 Terminal

    The EXPLORER 500 is a compact unit comprising antenna, compass, display and keypad, all in one unit. Display and keypad The EXPLORER 500 has a display and a keypad for displaying status and for setting up the EXPLORER 500. Power indicator...
  • Page 18 Chapter 1: Introduction Light indicators The EXPLORER 500 has two light indicators next to the display: a green power indicator and a red message indicator. Green Power indicator The function of the green Power indicator to the left of the display is as follows:...
  • Page 19 No installation of software is needed if you connect using LAN. If you connect using USB you need to install a USB driver for the computer to recognize the EXPLORER 500. See Using the USB interface on page 67.

  • Page 20: Matrix Of Services And Communication Interfaces

    This chapter has provided an overview of the BGAN system and of the EXPLORER 500. The next chapters will go into more detail about how to set up and use the EXPLORER 500. The following chapter, Getting started, explains how to unpack and start up the EXPLORER 500, and how to point the antenna in order to get the best possible signal.

  • Page 21: Chapter 2 Getting Started

    • how to insert and remove the battery and SIM card, and • how to start up the EXPLORER 500 and make the first call or data session. Unpacking and assembling Unpacking Unpack the EXPLORER 500 and accessories and check that the following items are present:...
  • Page 22 Chapter 2: Getting started Inserting the SIM card The EXPLORER 500 is delivered with the battery separated from the terminal. If the battery is already inserted, remove it as described in Removing the battery on page 13. The SIM card is provided by your Airtime Provider. Insert the SIM card as follows: Insert the SIM card into the SIM slot.
  • Page 23 Chapter 2: Getting started Removing the battery To remove the battery, do as follows: Locate the slide lock at the bottom of the unit. 2. Slide the lock aside to release the battery from the unit. 3. Remove the battery. TT 98-122274-O...
  • Page 24 Chapter 2: Getting started Removing the SIM card To remove the SIM card, first remove the battery as described in Removing the battery on page 13. Note When the SIM card is removed, you cannot use the display menu system nor make calls or start data sessions.

  • Page 25: Placing The Explorer™ 500

    Place the EXPLORER 500 with the battery facing down. • Place the EXPLORER 500 so that water, e.g. from rain, is led away from the terminal. The EXPLORER 500 is protected against splashing water and dust (IP-54) but is not water-proof. It must under no circumstances be submerged into water.
  • Page 26 Connecting to power You can connect the DC input to power without the battery inserted. If the battery is inserted when you apply power to the EXPLORER 500, the battery is automatically recharged. Connecting to a 100-240 V AC electrical outlet: Connect the AC/DC adapter to the DC Power input on the side of the EXPLORER 500.

  • Page 27: Powering The Explorer™ 500

    The default behavior of the EXPLORER 500 is to power up automatically when you connect the power cable. If you wish, you can change this power up mode, so that the EXPLORER 500 is only powered if the Power button is pressed.

  • Page 28: Options For The Start-Up Procedure

    Chapter 2: Getting started Options for the start-up procedure Overview of the start-up options You have different options for the start-up procedure. Each of these options are briefly described in this section. For information on how to enter PIN and point the antenna, see the subsequent sections. The following drawing shows the options available after power on.
  • Page 29 “Full” procedure (1) After power on, enter the PIN and then point the antenna. In this mode you have full access to the EXPLORER 500, that is you can use the menu system and communicate on the BGAN network. The display will show READY when the menu system is not activated.

  • Page 30: Entering The Sim Pin

    Entering the SIM PIN Overview You have to enter a PIN to use the EXPLORER 500, unless the use of PINs is disabled e.g. from the BGAN LaunchPad. The first time you are asked for a PIN, you can choose to cancel (press C). If you cancel, you are asked again after pointing is completed.

  • Page 31: Pointing The Antenna

    The next sections describe how to point the antenna for the best possible signal. Pointing data If the position of the satellite in relation to the EXPLORER 500 is known, you can use the compass to roughly point the antenna in the right direction. If you know the Azimuth and the Elevation, you can use this data to adjust the antenna.
  • Page 32 Chapter 2: Getting started Required signal strength As a rule of thumb, the signal strength should typically be 45 dBHz or more for the EXPLORER 500 to be able to establish a call or data session. However, the required signal strength can vary depending on a number of factors, such as weather conditions and location.
  • Page 33 BGAN network. This is called obtaining a GPS fix. If the antenna is placed in an open location with a wide view to the sky, the EXPLORER 500 will probably obtain the GPS fix automatically while you are pointing towards the BGAN satellite.
  • Page 34 Chapter 2: Getting started Pointing the antenna towards the satellite To help you obtain the best possible signal strength, the EXPLORER 500 uses a pointing sound to indicate the signal strength during pointing. The frequency of the tone increases with the signal strength.
  • Page 35 NO GPS. For further information, see the Troubleshooting Guide on page 139. • READY or DATA: READY means the EXPLORER 500 is registered on the network and is ready to go online. If you have already connected a computer, the display shows DATA instead of READY.

  • Page 36: Using An External Antenna (Fixed Installation)

    External antenna on page 159. Using a fixed EXPLORER™ 500 (semi-fixed installation) You can keep the EXPLORER 500 in a fixed position, using the Pole mount kit for EXPLORER 500. See Options and accessories on page 137 for information on type number.

  • Page 37: Making The First Call

    Mobile subscriber number: The mobile subscriber number of the EXPLORER 500 you are calling. If the mobile subscriber numbers of the EXPLORER 500 are available on the SIM card, they are listed in the display menu system of the EXPLORER 500 under PROPERTIES > MOBILE NUMBERS.
  • Page 38 EXPLORER 500 (Phone/Fax or Bluetooth). To be able to receive a call with a Bluetooth handset, the handset must be paired with the EXPLORER 500. For information on how to pair Bluetooth devices, see Bluetooth pairing on page 51. Note A connected phone will only ring if the call type is set correctly.

  • Page 39: Making The First Data Connection (Lan)

    Chapter 2: Getting started Making the first data connection (LAN) Before connecting to the LAN interface For the LAN (Local Area Network) interface to work without any further setup, the computer must be set up to obtain an IP address and a DNS server address automatically. To check these settings on your computer, do as follows (For Windows®...

  • Page 40: What's Next

    Browser settings on page 76. What’s next? After reading this chapter you should be able to start up the EXPLORER 500 and make a simple data or voice connection. The next chapters provide more information on the user interfaces and the setup of the EXPLORER 500.

  • Page 41: Chapter 3 Using The Display And Keypad

    Using the display and keypad In this chapter This chapter describes how to use the built-in display menu system of the EXPLORER 500. It contains an overview of the entire menu system followed by a description of each menu. It also explains the symbols and messages that may appear in the display, and describes how to navigate using the keypad.
  • Page 42 For information on how to navigate in the menu system, see Navigating the display and keypad on page 35. Menu drawing The below drawing shows an overview of the menus in the display menu system of the EXPLORER 500. <message 1> <message 2> Start up <message 3>...

  • Page 43: Display During Start-Up

    If the GPS position has not yet been acquired at this point, the display will show NO GPS. For further information, see the Troubleshooting Guide on page 139. READY: The EXPLORER 500 is registered on the network and is ready to go online. •...

  • Page 44: Display Symbols

    Chapter 3: Using the display and keypad Display symbols Apart from the menu text, the display can show various symbols. Below is a list of the possible symbols with an explanation to each symbol. Symbol Explanation The battery charge level. When the level is too low (below 10%) the icon flashes.

  • Page 45: Navigating The Display And Keypad

    STEALTH ACTIVATED for a moment; then all lights and sounds are turned off. Note For Stealth mode to be available, it must be enabled in the EXPLORER 500. Refer to Enabling or disabling stealth mode on page 41. •...

  • Page 46: The Menus

    Chapter 3: Using the display and keypad Display text When you have not entered the menu system, the Main screen shows the currently most important information. Refer to Dynamic information in the display on page 46. CANCEL in the left side of the display means: Press C to cancel the current operation. OK in the right side of the display means: Press OK to accept the current operation.

  • Page 47: Messages Menu

    Chapter 3: Using the display and keypad Messages menu Viewing the list of messages To see the list of SMS messages, enter the menu system and select MESSAGES. Each message is listed with the name (if known) or the number of the sender. An unopened folder indicates an unread message and an opened folder indicates a read...

  • Page 48: Connect Menu

    Chapter 3: Using the display and keypad Connect menu Streaming Profiles Using the web interface you can define a number of Profiles for data transmission. The Streaming Profiles defined and selected for the LAN interface appear in the CONNECT menu, and can be started and stopped using the keypad.

  • Page 49: Calls Menu

    Chapter 3: Using the display and keypad Calls menu To see a list of calls and data sessions, do as follows: Select CALLS. 2. Select one of the following: • MISSED: to see a list of incoming calls that were not answered. •...

  • Page 50: Settings Menu

    Select SETTINGS > DISPLAY > CONTRAST. 2. Select one of the following: • AUTOMATIC: to let the EXPLORER 500 automatically adjust the contrast according to the temperature. The contrast of the display is affected by the temperature. The EXPLORER 500 can automatically adjust the contrast so that the display looks the same, regardless of changes in the temperature.
  • Page 51 3. Select ON or OFF to enable or disable the selected interface. Enabling or disabling stealth mode When the EXPLORER 500 is in stealth mode, all lights and sounds are turned off. You can still use the EXPLORER 500, and the display text is readable.
  • Page 52 • AUTOMATIC: to have the EXPLORER 500 power on automatically when external power is applied. • MANUAL: to have the EXPLORER 500 power on only when the Power button is pressed. Restoring settings You can restore default values for the settings in the SETTINGS menu, except the contrast setting.

  • Page 53: Properties Menu

    Properties menu Viewing known Bluetooth devices You can view a list of the Bluetooth devices that are paired with the EXPLORER 500. The devices are listed with their Bluetooth names. The devices in this list can communicate with the EXPLORER 500 without any further setup.
  • Page 54 2. Select one of the following options: • IP ADDRESS to see the IP address of the EXPLORER 500. This IP address is used to access the web interface of the EXPLORER 500. The web interface is a built-in web server used to configure and set up the EXPLORER 500.

  • Page 55: Help Desk

    If the information is not available on the SIM card, you can use the built-in web interface of the EXPLORER 500 to store the help desk name and number. For further information, see Accessing the Help desk on page 132.

  • Page 56: Dynamic Information In The Display

    To see the voice mail service number, select PROPERTIES > VOICE MAIL NUMBER Alarms When alarms are issued in your EXPLORER 500, the display indicates the number of new alarms, and the red message indicator is flashing. To view currently active alarms, press OK. To ignore and continue, press C.

  • Page 57: What's Next

    Streaming data has the highest priority, then CS calls and then Background data. Within these categories, the oldest calls/data sessions have the highest priority. WARNING! When the EXPLORER 500 is powered on, stay clear of the antenna front! The antenna emits radio frequency energy, not only when a call or data session is in progress.

  • Page 58: Chapter 4 Using The Interfaces

    Using the interfaces In this chapter This chapter describes how to use the interfaces of the EXPLORER 500. For each connection type it describes how to connect cables and the necessary setup to establish a connection. It does not describe advanced configuration of interfaces. For this type of information, refer to the “Configuring...”...

  • Page 59: Services And Interfaces

    Chapter 4: Using the interfaces Services and interfaces A variety of services can be accessed from different interfaces on the EXPLORER 500. The following table shows the possible combinations of services and interfaces, and which types of equipment can be used.

  • Page 60: Enabling Or Disabling An Interface

    Chapter 4: Using the interfaces Enabling or disabling an interface Overview By default, all interfaces are enabled. However, you can disable the LAN interface, the Bluetooth interface and/or the Phone/Fax interface in order to minimize the power consumption. Note The USB interface cannot be disabled; it is always enabled. Using display and keypad To enable or disable an interface using the display and keypad, do as follows: Enter the menu system.

  • Page 61: Bluetooth Pairing

    The default Bluetooth name of the EXPLORER 500 is EXPLORER 500. If there is more than one EXPLORER 500 in the list, you can use the MAC address to locate the correct one. To see the MAC address of your EXPLORER 500, enter the display menu system and select PROPERTIES >...

  • Page 62: Using A Phone Or Fax Machine

    2. From the left navigation pane, select SETTINGS and select the Phone/Fax or Bluetooth. 3. At Outgoing calls, select Standard or 3.1 kHz Audio. Up to 7 Bluetooth devices can be paired with the EXPLORER 500. Remember to set the call type for each paired handset in the BLUETOOTH VOICE DEVICES list.
  • Page 63 3. At Incoming Calls, check Standard or 3.1 kHz Audio or both. For Bluetooth, remember to set the call type for each handset in the BLUETOOTH VOICE DEVICES list. If the call type used for a call to the EXPLORER 500 is not selected in the web interface, the connected phone will not ring.

  • Page 64: Connecting An Analog Phone Or A Fax Machine

    2. Connect the other end of the cable to the Phone/Fax connector on the EXPLORER 500. 3. Power up the EXPLORER 500 and point the antenna as described in Pointing the antenna on page 21. 4. Check the connection by making a phone call or sending a fax.

  • Page 65: Connecting A Bluetooth Handset

    Connecting a Bluetooth handset Before connecting a Bluetooth handset To use a Bluetooth handset with the EXPLORER 500, you first have to pair the two devices. For information on pairing devices, see Bluetooth pairing on page 51. The Bluetooth handset must be placed within a maximum distance of 100 m from the EXPLORER 500.

  • Page 66: Entering The Sim Pin Using A Phone

    Entering the SIM PIN using a phone Entering the PIN If you have a phone connected to the EXPLORER 500, you can use it to enter the PIN at start up, as an alternative to the keypad. Do as follows: Dial the PIN the same way you would dial a phone number: •...

  • Page 67: Making Or Receiving A Phone Call With The Explorer™ 500

    Refer to Selecting the incoming call type on page 53. Information of missed calls is stored in the call log of the EXPLORER 500. You can view the call log with the display menu system or the web interface. See Calls menu on page 39 or Viewing the lists of calls on page 86.

  • Page 68: Making A Call To The Explorer™ 500

    Chapter 4: Using the interfaces Making a call to the EXPLORER™ 500 To make a call to a phone connected to the EXPLORER 500, dial +870 <Mobile subscriber number> • + is the prefix used in front of the country code for international calls. This is 00 when calling from countries in Europe and from many other countries.

  • Page 69: Dialing Functions

    0900 followed by # or off-hook key Local call broadcast to all handsets. Apart from the numbers above, the EXPLORER 500 uses the following dialing prefixes: • 1* before the phone number will force the connection to use Standard Voice.
  • Page 70 Note You cannot make local calls between two Bluetooth handsets through the EXPLORER 500. You can only make local calls between an analog phone and a Bluetooth handset. Up to 7 Bluetooth handsets can be connected at the same time, but only one call can be active on the Bluetooth interface.
  • Page 71 The EXPLORER™ Bluetooth Handset uses a softkey in stead of the R key. When you receive a call, you can transfer this call to another phone or headset connected to the EXPLORER 500. To transfer the incoming call to another phone or headset, do as follows: Press R 4 * <local number>...

  • Page 72: Sending Or Receiving A Fax Message

    Overriding the default outgoing call type on page 52. Receiving a fax message An analogue fax machine connected to the EXPLORER 500 can only receive a fax with 3.1 kHz Audio. Refer to Selecting the incoming call type on page 53.

  • Page 73: Using A Computer

    Using a computer Choosing an interface for data connection The EXPLORER 500 has three types of interface for data connection: LAN, USB and Bluetooth. The following table shows some characteristics of each interface, to help you choose the right interface for your application.

  • Page 74: Standard Or Streaming Data

    Using Profiles on page 127 and Using a Traffic Flow Template on page 130. Setting up and activating a Streaming connection By default, any data connection on the EXPLORER 500 is a Standard data connection. If you want to set up a Streaming connection, select a Streaming Profile when setting up your data interface.

  • Page 75: Using The Lan Interface

    The LAN interface is configured as MDI-X. This means that if you are connecting your computer directly to the EXPLORER 500, you should use a straight cable. If you are connecting a switch to the EXPLORER 500, use a crossed cable.
  • Page 76 4. Check the connection, e.g. by starting your Internet Browser. If connection fails, check that the interface is enabled in the EXPLORER 500. If the LAN icon is not present in the display Main screen and in the Home window of the web interface, the interface is disabled.

  • Page 77: Using The Usb Interface

    First time setup of USB If it is the first time you connect your computer to the EXPLORER 500 using the USB interface, or you have exchanged the EXPLORER 500 with another EXPLORER 500, you must install a driver as follows: Power up your computer.
  • Page 78 3. Connect the other end of the cable to the USB connector on the EXPLORER 500. 4. Power up the EXPLORER 500 and point the antenna as described in Getting started on page 11. 5. To enable communication on the USB interface, open your dial-up connection as described in the following steps.
  • Page 79 Chapter 4: Using the interfaces Using 64 kbps UDI (ISDN) through the USB interface You can communicate using ISDN through the USB interface of the EXPLORER 500, provided that your Internet Service Provider (ISP) supports Unrestricted Digital Information (UDI) and that it is included in your subscription.

  • Page 80: Using A Computer With Bluetooth

    For a list of supported Bluetooth profiles, see Bluetooth interface on page 157. The computer should be placed within a maximum distance of 100 m from the EXPLORER 500. Note that this is the maximum distance in open air; the actual maximum distance may be shorter, depending on the environment.

  • Page 81: Creating A Dial-Up Connection

    2. Connect the USB cable between your computer and the USB connector on your EXPLORER 500, or place your paired Bluetooth computer close to the EXPLORER 500. For information on Bluetooth, see Using a computer with Bluetooth on page 70.
  • Page 82 *98# if you want a Standard data connection to the Internet and/or the web interface, or *99# if you are going to connect only to the web interface of the EXPLORER 500. To dial up using a specific Profile, type *98*<CID>#.

  • Page 83: Additional Interfaces

    3. Connect the other end of the cable to your EXPLORER Bluetooth Handset. If the EXPLORER 500 is connected to power, the battery of the Bluetooth Handset is now recharged. TT 98-122274-O...

  • Page 84: What's Next

    This chapter has described the basics of how to set up and use each interface. The following chapter, Using the web interface, describes how to use the built-in web interface for setting up and using the EXPLORER 500. TT 98-122274-O...

  • Page 85: Chapter 5 Using The Web Interface

    The web interface What is the web interface? The web interface is a built-in web server in the EXPLORER 500, used for operating, setting up and configuring the EXPLORER 500. You can access the web interface from a standard Internet browser.
  • Page 86 Chapter 5: Using the web interface Browser settings If you are connecting your computer using the LAN interface, the Proxy server settings in your browser must be disabled before accessing the web interface. Most browsers support disabling of the Proxy server settings for one specific IP address, so you can disable Proxy server settings for the web interface only, if you wish.

  • Page 87: Accessing And Navigating The Web Interface

    3. Open your browser and enter the IP address of the EXPLORER 500. The standard IP address is 192.168.0.1. If your EXPLORER 500 uses a different IP address, you can look it up by entering the display menu system of the EXPLORER 500 and selecting PROPERTIES >...
  • Page 88 Chapter 5: Using the web interface • The navigation pane holds the main menu. Clicking an item in the menu opens a submenu in the navigation pane or a new page in the contents section. • The status field shows battery status and signal strength. •...

  • Page 89: Entering The Sim Pin In The Web Interface

    If you enter a wrong PIN 3 times you are asked for a PUK (PIN Unblocking Key). For further information, see Wrong PIN on page 20. If the PIN has already been accepted in the EXPLORER 500, or the PIN is disabled e.g. from the BGAN LaunchPad, the web interface goes directly to the Home window at start-up.

  • Page 90: The Home Window

    The TERMINAL section of the Home window shows the following: • Status. The status of the EXPLORER 500. This field corresponds largely, but not completely, to the status information in the display. Examples of status information are: Ready, Registering and Data.

  • Page 91: Managing Calls And Data Sessions

    Chapter 5: Using the web interface Managing calls and data sessions Start/stop a Streaming session on the LAN interface Note Before starting a Streaming session, make sure you have set up a Streaming Profile and activated it in the SETTINGS > LAN window. To start or stop a Streaming session, click the relevant link under STREAMING PROFILES ON LAN.

  • Page 92: Pointing Using Web Interface

    3. When you have obtained the highest signal strength you can get, click Accept. The web interface now returns to the Home window, and the EXPLORER 500 tries to establish a connection and register on the BGAN network.

  • Page 93: Using The Phone Book

    Chapter 5: Using the web interface Using the phone book General usage Overview In the phone book you can: • Look up phone numbers. • Look up short dial numbers for easy dialing from an analog or Bluetooth handset. • Modify or delete existing names and phone numbers, or enter new names and phone numbers.

  • Page 94: Editing Phone Book Entries

    The entry number in the phone book is the Short dial number. When making a call from the EXPLORER 500 you can use this number instead of dialing the entire phone number. Simply dial 0 <short dial> followed by # or off-hook key.

  • Page 95: Call Log

    3.1 kHz Audio. Exporting the call log The EXPLORER 500 logs all calls and data sessions. For information on how to view the lists of calls and data sessions, see the next section. To export the entire call log to a file, do as follows: In the CALLS window, click the link Export total Call Log to file.

  • Page 96: Viewing The Lists Of Calls

    Chapter 5: Using the web interface Viewing the lists of calls To see information on outgoing, received or missed calls or data sessions, select one of the following lists from the left navigation pane in the CALLS window: • Outgoing calls shows the start time, receiving end phone number, duration, type (Standard or 3.1 kHz Audio) and estimated charge of each outgoing call.

  • Page 97: Handling Messages

    Sending an SMS message from the EXPLORER™ 500 Important If the EXPLORER 500 is not online when you attempt to send a message, the message is moved to the Outbox in stead of the Sent folder. Messages in the Outbox are not automatically sent when the EXPLORER 500 goes online. For further information on the Outbox, see the next section, Options for messages in the Outbox.

  • Page 98: Options For Messages In The Outbox

    91. 6. Click Send. If the EXPLORER 500 is online, the message is now sent and moved to the Sent folder. Options for messages in the Outbox Messages in the Outbox are messages that have not been sent, e.g. because the EXPLORER 500 was not online when you attempted to send the messages.

  • Page 99: Sending An Sms Message To The Explorer™ 500

    Chapter 5: Using the web interface Sending an SMS message to the EXPLORER™ 500 You can send an SMS message to the EXPLORER 500 e.g. from a mobile phone, using one of the mobile subscriber numbers for voice. Dial +870 <Mobile subscriber number>...

  • Page 100: Options For New Sms Messages

    Chapter 5: Using the web interface Options for new SMS messages To see new messages, click MESSAGES from the left navigation pane. Besides viewing the new messages, you have a number of options for what to do with each message: •...

  • Page 101: Configuring Message Settings

    Chapter 5: Using the web interface Configuring message settings Setting up the default message options You can set up general options for your outgoing messages. These settings apply by default to all your outgoing messages. Note, however, that you can change the Delivery notification setting for an individual message.
  • Page 102 Chapter 5: Using the web interface Viewing or changing SMS service center number The SMS service center number identifies the SMS service center used when sending and receiving SMS messages. The SMS service center number is stored on the SIM card. •...

  • Page 103: Explorer™ 500 Settings

    Pointing at power up If the EXPLORER 500 is placed in a fixed position it may not be necessary to go through the pointing process every time the EXPLORER 500 is powered. You can set up the EXPLORER 500 to automatically establish a connection to the BGAN network, if you know that the signal strength is sufficient.

  • Page 104: Setting The Display Backlight And Contrast

    If you have selected that pointing is not required at power up, the start up procedure will be as follows: Power up. 2. Enter the PIN. After the PIN is accepted, the EXPLORER 500 immediately tries to connect to and register on the BGAN network. Automatic power up In the Power up section of the SETTINGS window, select whether or not the EXPLORER 500 should switch on automatically when external power is applied.

  • Page 105: Turning Audio Indicators On Or Off

    This setting is a default setting. When the EXPLORER 500 is in pointing mode, you can toggle pointing sound on/off for the current pointing process using on the keypad of the EXPLORER 500.

  • Page 106: Setting Up The Interfaces

    APN (Access Point Name) The APN is used by the EXPLORER 500 user to establish the connection to the required destination network. This means that the EXPLORER 500 must know the APN in order to be able to connect to the destination network.
  • Page 107 If more than one user is connected to the LAN interface of the EXPLORER 500, it is necessary to use a switch, as the EXPLORER 500 only has one LAN connector. If more than one user is connected using a switch, you must select Router mode to use the NAT of the EXPLORER 500.

  • Page 108: Configuring The Usb Interface

    Chapter 5: Using the web interface Configuring the USB interface Note The USB interface cannot be turned off; it is always on. For an explanation of each of the data settings, see Description of data settings on page 96. To configure the USB interface, do as follows: Select SETTINGS >...
  • Page 109 Chapter 5: Using the web interface If you select Enabled, the Header information of each data packet will be compressed, leaving more bandwidth for the actual data. For further information, see Header compression on page 96. 4. Select the source of the APN. There are four options for setting the APN.

  • Page 110: Configuring The Lan Interface

    Chapter 5: Using the web interface Configuring the LAN interface Data settings For an explanation of each of the data settings, see Description of data settings on page 96. CAUTION! If you are connected using LAN while changing the settings below, your changes may affect your current connection.
  • Page 111 Chapter 5: Using the web interface 3. Under NAT mode, select whether the EXPLORER 500 should run in Router mode or in Modem mode. Router mode is recommended for most purposes. Select Router mode if one or more computers are connected using the LAN interface, and the EXPLORER 500 should act as a router.
  • Page 112 Chapter 5: Using the web interface 10. Select the Primary Profile. Select a Profile from the Primary scroll list. This Profile is used by the LAN interface as a first choice, when possible. There are 4 predefined Profiles: Standard, Streaming 32 kbps, Streaming 64 kbps and Streaming 128 kbps.
  • Page 113 Chapter 5: Using the web interface Port forwarding Port forwarding enables you to setup a server connected to the EXPLORER 500 while the terminal is in Router mode. Without port forwarding it would not be possible to contact the server from the internet.

  • Page 114: Configuring The Bluetooth Interface

    Chapter 5: Using the web interface Configuring the Bluetooth interface For an explanation of each of the data settings, see Description of data settings on page 96. To configure the Bluetooth interface, do as follows: Select SETTINGS > Bluetooth. 2. Under BLUETOOTH VOICE DEVICES, set the voice quality for incoming and outgoing calls. All paired voice devices are listed with their local phone numbers.
  • Page 115 Chapter 5: Using the web interface 3. For data devices, the settings are listed under the Bluetooth profile that is used (Dial-up network or LAN). The next steps describe the settings available under a Bluetooth profile. 4. Under IP Header compression, select Enabled or Disabled. For information on Header Compression, see Header compression on page 96.
  • Page 116 Chapter 5: Using the web interface 8. Select the Primary Profile. Select a Profile from the scroll list. This Profile is used by the Bluetooth interface as a first choice, when possible. There are 4 predefined Profiles: Standard, Streaming 32 kbps, Streaming 64 kbps and Streaming 128 kbps.

  • Page 117: Pairing Bluetooth Devices From The Web Interface

    3. In the web interface, select SETTINGS > Bluetooth and make sure that Bluetooth is Enabled. 4. Use the predefined Device name or type in a new name for your EXPLORER 500. The Device name is shown to other Bluetooth devices, if the EXPLORER 500 is configured to be shown (refer to step 6.
  • Page 118 Chapter 5: Using the web interface 6. Next to Visibility, select Show or Hide. • If you select Show, the device name of the EXPLORER 500 is shown to other Bluetooth devices that are searching for devices. • If you select Hide, other Bluetooth devices will not see the EXPLORER 500.
  • Page 119 2. Select SETTINGS > Bluetooth > Paired devices. The list shows all devices that are paired with the EXPLORER 500. You can see the name, Class of Device, status (whether or not a device is currently connected) and local phone number.

  • Page 120: Configuring The Phone/Fax Settings

    Chapter 5: Using the web interface Configuring the Phone/Fax settings Do as follows: Select SETTINGS > Phone/Fax from the left navigation pane. 2. Select Enabled or Disabled to enable/disable the Phone/Fax interface. 3. Set the voice quality for incoming and outgoing calls. Voice quality is described in more detail in Selecting the call type on page 52.

  • Page 121: Setting Up Call Services

    Setting up call services Overview Note The EXPLORER 500 must be registered on the BGAN network before you can set up the call services in the web interface. In the web interface you can set up the following supplementary services: •...
  • Page 122 Chapter 5: Using the web interface Call forwarding You can forward incoming calls to another phone number. Do as follows: Select Settings > Phone/Fax > Call forward from the left navigation pane. 2. For each call type, select Enabled next to the situation(s) in which you want to forward incoming calls.
  • Page 123 Chapter 5: Using the web interface Call barring You can bar incoming and/or outgoing calls to and from the EXPLORER 500. Do as follows: Select Settings > Phone/Fax > Call barring from the left navigation pane. 2. Click OK next to Read current settings, to make sure the window is updated.
  • Page 124 Chapter 5: Using the web interface 4. In the Barring PIN field at the bottom, type in a PIN for your call barring setup. Note This is not the SIM PIN entered at startup, but a second PIN which is supplied together with your SIM PIN.
  • Page 125 Chapter 5: Using the web interface Line identification You can set up the terminal to show your number when you are making a call or transmitting data on the Phone/Fax interface. Do as follows: Select Settings > Phone/Fax > Line identification from the left navigation pane. 2.
  • Page 126 Chapter 5: Using the web interface Closed user group Your subscription may include one or more closed user groups. A closed user group is a group of users permitted to make calls to each other but not to users outside the group. To define the settings for these user groups, do as follows: Select Settings >...

  • Page 127: Setting A Common Apn

    Chapter 5: Using the web interface 5. Select Preferential if you want the activated user group to be selected when a member of a user group does not specify the group number during call set up. Note that if you selected Subscribed above, this setting will not be used.

  • Page 128: Selecting The Gps Antenna

    Note This feature is only available in software version 1.07 and greater. The EXPLORER 500 can obtain the GPS position in two ways: Using the built-in GPS antenna or using the BGAN I-4 antenna. If the terminal is placed in an open location with a wide view to the sky, the GPS antenna is the better choice, because it is omnidirectional.

  • Page 129: Properties, Software Upload And Alarm List

    Chapter 5: Using the web interface Properties, software upload and alarm list Viewing the properties of the EXPLORER™ 500 To view the properties of the EXPLORER 500, select PROPERTIES from the left menu. The PROPERTIES window shows: • Local IP address. The local IP address of the EXPLORER 500.

  • Page 130: Uploading Software

    Chapter 5: Using the web interface Uploading software You can upload software to the EXPLORER 500 without entering the PIN. However, if the PIN is not entered, you must enter the Administration user name and password. To upload software to the EXPLORER 500, do as follows: Acquire the new software version from Thrane &...

  • Page 131: Viewing The Alarm List

    Chapter 5: Using the web interface Viewing the Alarm List When an alarm is issued, the web interface shows an alarm icon in the icon bar. To view the Alarm list, click the alarm icon from the icon bar at the top of the web interface or select Properties >...

  • Page 132: Administration

    Chapter 5: Using the web interface Administration Accessing the administration settings Logging on The Administration settings require an Administration user name and password. Select ADMINISTRATION from the left navigation pane. 2. Enter the Administration user name and password. The default user name is admin and the default password is 1234. In software version 1.07 and greater, if you have forgotten the administrator password, you can reset the password by clicking the link at the bottom of the window.
  • Page 133 Chapter 5: Using the web interface Resetting the Administrator password Note This feature is only available in software version 1.07 and greater. If you have forgotten the administrator password, do as follows: Contact your supplier for a reset code. Please report the serial number and IMEI number of the terminal. 2.
  • Page 134 Chapter 5: Using the web interface Changing the administrator password Do as follows: After entering the Administrator user name and password in the ADMINISTRATION window, locate the section Change administrator logon. 2. Type in the existing user name. 3. Type in the new password and retype the password on the next line. 4.
  • Page 135 Chapter 5: Using the web interface Saving a configuration to a file If you need to reuse a configuration in another EXPLORER 500, you can save your current configuration to a file, which can then be loaded into the other EXPLORER 500.
  • Page 136 Chapter 5: Using the web interface The entered tariffs are used for estimating the charges for calls and data sessions. The estimated charge is listed for each call or data session in the call log. For further information, see Viewing the lists of calls on page 86. Log handling From the left navigation pane in the ADMINISTRATION window, select Log Handling.

  • Page 137: Using Profiles

    Chapter 5: Using the web interface Using Profiles What is a Profile? A Profile is a collection of Quality of Service (QoS) settings and other settings defining the mode in which data is transmitted on an interface. For example, a Profile is used to define whether the connection is a Streaming connection or a Standard connection.
  • Page 138 Chapter 5: Using the web interface Defining new Profiles When you define your Profiles you can select Subscribed for many of the settings. If you select Subscribed, the value given in your Airtime subscription will automatically be used. To define a new Profile, do as follows: From the left navigation pane, select ADMINISTRATION >...
  • Page 139 10. In the Transfer delay (ms) row, type in the delay in ms. This is the delay from data is received in the EXPLORER 500 until it arrives at the receiving end. 11. In the Traffic handling priority row, select from the drop-down list which priority this connection should have.

  • Page 140: Using A Traffic Flow Template

    What is a Traffic Flow Template? A Traffic Flow Template (TFT) is a packet filter list allowing the Core network and the EXPLORER 500 to classify packets received from the external network into the proper PDP (Packet Data Protocol) context.
  • Page 141 • Protocol number. • Destination port range (From and To).Note that Source and Destination are relative the core network. This means that Destination is your EXPLORER 500 terminal. • Source port range (From and To). • Type of Service + Type of Service mask.

  • Page 142: Help Desk And Diagnostic Report

    If the Help desk number is available on the SIM card, the number is displayed as a link. To change the number, click the link, change the number and click Apply. If you need help with EXPLORER 500 issues you should call your local distributor.

  • Page 143: What's Next

    Chapter 5: Using the web interface What’s next? This chapter has explained how to use the web interface for setup and use of the EXPLORER 500. You should now be able to set up the EXPLORER 500, pair Bluetooth devices, check status, read and send SMS messages, use the phone book and much more.

  • Page 144: Chapter 6 Maintenance And Troubleshooting

    To see the help desk number, enter the display menu system or the web interface of your EXPLORER 500 and select HELP DESK. This help desk number is either taken from the SIM card or entered manually. If no number is available under HELP DESK, check your Airtime subscription for a contact number.

  • Page 145: Uploading Software

    (1 month), charge the battery to minimum 20 to 30% and remove it from the EXPLORER 500. If the Battery is stored for more than a month, see Storage at the end of this section.
  • Page 146 If the battery is not to be used for a longer period of time, do as follows: Fully charge the battery. 2. Remove external power. Then use the EXPLORER 500 or leave it on until the display shows a battery capacity of approximately 50%.

  • Page 147: Options And Accessories

    Desktop charger cradle for EXPLORER™ Bluetooth Handset + power supply TT-3686L EXPLORER 500 Battery EXPLORER™ External antenna + antenna cable TT-3008I Pole mount kit for EXPLORER 500 External antenna TT-3650A, Opt. 920 TT-3650A, Opt. 202 EXPLORER 500 Softbag EXPLORER 500 Dummy Battery TT-3686F TT-3650A, Opt.

  • Page 148: Troubleshooting Guide

    EXPLORER 500 is switched on. The EXPLORER 500 The Power button was not When you switch off the EXPLORER 500, cannot be switched pressed long enough. hold the power button until the display off. shows “Switching off”.
  • Page 149 NO GPS. unable to register on the is not blocked. network, because the GPS To obtain GPS fix, the EXPLORER 500 position is unknown. should be placed flat on an even surface pointing straight upwards, with a clear view to as much of the sky as possible.
  • Page 150 GPS. If the EXPLORER 500 has To help the EXPLORER 500 obtain GPS not been used recently fix, it should be placed flat on an even within the same location, it...
  • Page 151 154. Incoming calls: The voice Make sure the voice quality used for quality used for the call is calls to the EXPLORER 500 is selected in not selected in the web the web interface. Access the web interface.
  • Page 152 51. Incoming calls: The voice Make sure the voice quality used for quality used for the call is calls to the EXPLORER 500 is selected in not selected in the web the web interface. Access the web interface.
  • Page 153 Chapter 6: Maintenance and troubleshooting Problem Possible Cause Remedy A USB connection The cable is not properly Connect the cable. cannot be connected. established. The cable type or For information on the correct type of connector type is not connector and cable, refer to USB correct.
  • Page 154 Remedy A Bluetooth data The interface is off in the Enable the interface by entering the connection cannot be EXPLORER 500. display menu system and selecting SETTINGS > INTERFACES > established. BLUETOOTH > ON, or by accessing the web interface and selecting SETTINGS >...

  • Page 155: Status Signaling

    Chapter 6: Maintenance and troubleshooting Status signaling There are many ways of troubleshooting if an error occurs. The EXPLORER 500 has different means of status signaling, to help you find the cause of a problem: • Indicators. The function of the light indicators next to the display is described in Light indicators on page 8.
  • Page 156 Contact your distributor. SIM Module 00210 to The SIM interface on the Contact your distributor. Error 00219 EXPLORER 500 cannot be used. USB Module 00220 to The USB interface on the Contact your distributor. Error 00229 EXPLORER 500 cannot be used.
  • Page 157 Low ambient temperature Move the EXPLORER 500 to Too Low 01009 is causing the performance a warmer location. of the EXPLORER 500 to be For information on degraded or halted. temperature limits, see General specifications on page 151. Data rate...
  • Page 158 01400 to The EXPLORER 500 no Make sure the Signal Lost 01409 longer receives a signal EXPLORER 500 has a clear from the satellite. view to the satellite. Check that the antenna is pointed according to the position data. SIM Card...
  • Page 159 Failed Refer to Calls menu on page 39. If the problem persists, contact your distributor. External 02300 to The EXPLORER 500 is not Correct communication Antenna 02309 able to detect the external with the satellite requires Failure antenna type.

  • Page 160: Log Files

    Help desk and diagnostic report on page 132. Call log The call log holds information of up to 100 calls and data sessions to/from the EXPLORER 500. The call log contains detailed information such as date, time, phone numbers, duration, Mb transferred etc., for each call or data session.

  • Page 161: Appendix A Technical Specifications
