Liberty
LRI6E / Regency Horizon
®
MODELS: LRI6E-NG11 Natural Gas
HRI6E-NG11 Natural Gas
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
919-936d
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Insert
LRI6E-LP11 Propane
HRI6E-LP11 Propane
Installer: Please complete the details on the back cover
ANSI Z21.88-2017
and leave this manual with the homeowner.
CSA 2.33-2017
Homeowner: Please keep these instructions for future reference.
HRI6E
®
Installation Manual
Owners &
www.regency-fire.com
10.05.21
Advertisement
Table of Contents
Related Manuals for Regency Liberty LRI6E-NG11
Summary of Contents for Regency Liberty LRI6E-NG11
- Page 1 Liberty LRI6E / Regency Horizon HRI6E Owners & ® ® Gas Insert Installation Manual www.regency-fire.com MODELS: LRI6E-NG11 Natural Gas LRI6E-LP11 Propane HRI6E-NG11 Natural Gas HRI6E-LP11 Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Page 2 Congratulations! You are the owner of a state-of-the-art Gas Insert by Regency. The Regency Gas Insert Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a fireplace, at the flick of a switch. The models LRI6E / HRI6E of this series have been approved by Warnock Hersey for both safety and efficiency.
-
Page 3: Table Of Contents
table of contents OWNER'S INFORMATION Flue / Vent Installation ..........22 Levelling Leg Adjustment ..........23 On Demand Pilot Light ....3 (seven day safety timer) Air Shutter Adjustment ..........24 Copy of Safety Decals ...........9 System Data ..............25 MA Code - CO Detector ..........10 High Elevation ..............25 Important Message ............11 Gas Line Installation ............25... -
Page 4: Unit Dimensions With Vignette Faceplate
dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE " " " 1018 " " " UNIT DIMENSIONS WITH VIGNETTE FACEPLATE + SMALL 3 SIDED BACKING PLATE " " 1043 " " LRI6E / HRI6E-11 Direct Vent Gas Insert... -
Page 5: Unit Dimensions With Vignette Faceplate + Small Backing Plate + Spacer
dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE + SMALL BACKING PLATE + SPACER (1156mm) (94mm) (425mm) (1041mm) (262mm) (705mm) (770mm) (600mm) Not shown: Regular backing plate - 47-3/8" W. x 30-1/2" H. VIGNETTE FACEPLATE AND SMALL SPACER Oversize backing plate - 48-3/8" W. x 33" H. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. -
Page 6: Unit Dimensions With 4 Sided Vignette Faceplate + Backing Plate
dimensions UNIT DIMENSIONS WITH 4 SIDED VIGNETTE FACEPLATE + BACKING PLATE " " " 1203 " " 30-1/2 “ [775] 3-5/8 " [92] LRI6E / HRI6E-11 Direct Vent Gas Insert... -
Page 7: Unit Dimensions With Arched Vignette Faceplate + Backing Plate
dimensions UNIT DIMENSIONS WITH ARCHED VIGNETTE FACEPLATE (OPTIONAL) " " " " " 1153 " 16" " " " " UNIT DIMENSIONS WITH ARCHED VIGNETTE FACEPLATE + BACKING PLATE " " " " " 1293 " " " " " "... -
Page 8: Unit Dimensions With Arched Vignette Faceplate + Spacer 8 Unit Dimensions With Arched Vignette Faceplate + Spacer + Backing Plate
dimensions UNIT DIMENSIONS WITH ARCHED VIGNETTE FACEPLATE + SPACER " " " " " 1153 " " " " " " UNIT DIMENSIONS WITH ARCHED VIGNETTE FACEPLATE + SPACER + BACKING PLATE " " " " " 1293 " " "... -
Page 9: Copy Of Safety Decals
This is a copy of the labels that accompany each HRI6E/LRI6E Gas Insert (only LRI4E shown below). We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 10: Ma Code - Co Detector
requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 11: Important Message
CAN/CGA B149 (in Canada) or the National Fuel Gas Code ANSI Z223.1 in the U.S.A. This AND OTHERS MAY BE SUSCEPTIBLE The Regency Gas Insert must be installed in appliance should be installed by a qualified gas TO ACCIDENTAL CONTACT BURNS. A accordance with these instructions. -
Page 12: Lighting Procedure
owner's information LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has 3. After approximately 4 seconds the spark ignition system will spark for 60 several options for starting/operating the appliance using the power button seconds to light the pilot. and ON/OFF key on the hand held transmitter. -
Page 13: Copy Of Lighting Plate Instructions
owner's information COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 14: Proflame I Remote Control Operating Instructions
owner's information PROFLAME I REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 1 is an integrated part of the TECHNICAL DATA Proflame 1 System, which consists of these elements: REMOTE CONTROL • Proflame 1 Transmitter, to be used in conjunction with: •... - Page 15 owner's information Remote-Flame Control Temperature indication Display The Proflame has six (6) flame levels. With the system on, and the flame With the system in the "OFF" position, press the Thermostat Key and level at the maximum in the appliance, pressing the Down Arrow Key the Mode Key at the same time.
- Page 16 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual room to the AUX icon (fig.
- Page 17 owner's information LOW BATTERY POWER DETECTION Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (Fig.
-
Page 18: For Your Safety
installation GAS PRESSURE FOR YOUR SAFETY FACTORY-BUILT (METAL) WOOD- TESTING BURNING FIREPLACE This appliance requires air for proper combustion. REQUIREMENTS Always provide adequate combustion and The appliance must be isolated from the gas sup- ventilation air. Follow instructions and information ply piping system by closing its individual manual NOTE: Any parts that are removed must be removed in CAN/CGA B149 (in Canada) or the National Fuel... -
Page 19: Installation Checklist
MINIMUM FIREPLACE DIMENSIONS sections "Minimum Fireplace Dimensions and Clearances to Combustibles) The minimum fireplace clearances & dimensions for the Regency gas insert are shown in the following 2) Make the gas connection. (Refer to section "Gas diagrams: Connection") Gas connection is on the left side of the appliance. -
Page 20: Minimum Clearances To Combustibles
Otherwise: Min. Hearth requirements - An R value of 1.75 is required to meet the requirements Diagram 1 of the hearth in front of this appliance. 1" of Calcium Silicate board available from Regency, part number (296-936) plus 3/8" tile or equivalent would meet this requirement. -
Page 21: Gas Connection
installation GAS CONNECTION The Air Intake and exhaust pipes must be attached to the inlet and exhaust collars of the termination cap with a minimum of three screws per pipe. GAS CONNECTION WARNING: Only persons licensed to work Part # Description with gas piping may make the 948-305... -
Page 22: Flue / Vent Installation
installation FLUE / VENT INSTALLATION 4) Use the Flue Connector Slide Tool to slowly pull the Flue Connector NOTE: Flue Plate Connector Gasket Intake Liner Plate forward as you move the Insert rearward into the Fireplace Chase. must not be damaged or removed. Exhaust Liner Care must be taken to ensure that this Gear Clamps... -
Page 23: Levelling Leg Adjustment
installation LEVELLING LEG ADJUSTMENT The LRI6E / HRI6E inserts are equipped with 2 rear levelling legs that are accessible while the appliance is in its final installation position. The unit can be adjusted up to 5/16" (16mm). Remove left and right side filler pieces. The rear levelling bolts are located in the back corners of the firebox and can be adjusted using a 7/16" wrench. Rotate the bolts clockwise to raise the rear of the firebox. -
Page 24: Air Shutter Adjustment
CAUTION: Carbon will be produced if air shutter is closed too much. Unit Back Note: any damage due to carboning resulting from improperly setting the aeration controls is NOT covered under warranty. Push to close - Pull to open Note: Aeration Adjustment should only be performed by an authorized Regency Installer at the time of installation or service. 24 | LRI6E / HRI6E-11 Direct Vent Gas Insert... -
Page 25: System Data
38,000 Btu/h (11.14 kW) Minimum Input 25,000 Btu/h Note: If you have an incorrect flame pattern, (7.33 kW) contact your Regency dealer for further ® instructions. Incorrect flame pattern will have small, probably LRI6E-LP11 / HRI6E-LP11 yellow flames, not coming into proper contact SYSTEM DATA with the rear burner or flame sensor. -
Page 26: Optional Wall Thermostat Installation
installation OPTIONAL WALL THERMOSTAT INSTALLATION This installation must be completed during intial install prior to the faceplate being installed. A wall thermostat may be installed if desired. 1) Run wires from thermostat into the unit. 2) Remove the green wire marked (TH) at the white connector-shown below. The noted wires will be located near the gas valve. Green Wires CAUTION Do not wire... -
Page 27: Conversion From Ng To Lp
installation HRI6E / LRI6E-11 CONVERSION FROM NG TO LP CONVERSION FROM NG TO LP LRI6E/HRI6E using SIT 885 NOVA Gas Valve HRI6E/LRI6E0-11 using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! WARNING This conversion kit shall be installed by a qualified service agency in ac- cordance with the manufacturer’s instructions and all applicable codes and... - Page 28 HRI6E / LRI6E-11 installation 6) Re-attach the Pressure Regulator wire, and re-situate the Gas Valve, se- 10) Unscrew the pilot orifice with the allen key; then replace with the LPG pilot cure the screws that fasten the Gas Valve Mounting Brackets. orifice and the pilot cap, provided in the kit.
-
Page 29: Proflame Remote System Gtmf With Fan
installation PROFLAME REMOTE SYSTEM GTMF WITH FAN (LRI6E / HRI6E) WIRING DIAGRAM Proflame System Configuration 886 GTMF Wire Diagram SureFire™ Switch 0.584.622 0.584.907 Ground Black Neutral Green Live Fan Thermodisc Ground 120V AC 60 Hz (normally open) Black Black Black GTMF REMOTE SYSTEM - IMPORTANT: The 120V fan control module serves as the power source for this unit. -
Page 30: Glass Crystal / Optional Stone Installation
installation GLASS CRYSTAL / OPTIONAL STONE INSTALLATION Spread the Glass Crystals or Stones evenly over the burner. Ensure the crystals/stones do not overlap excessively as this will affect the flame pattern. IMPORTANT NOTE: Only the supplied approved Glass Crystals and Stones are to be used with these fireplaces. Use of any other type of glass crystals or stones can alter the unit's performance, any damage caused by the use of any unapproved glass or stones will not be covered under warranty. - Page 31 HZI540EB ADDENDUM installation CAUTION DO NOT place spa stones or volcanic stones over pilot and burner ports. No spa stones in this area. No volcanic stones in this area. | 31 LRI6E / HRI6E-11 Direct Vent Gas Insert 09/28/11...
-
Page 32: Hri6E Optional Log Set Installation
HRI6E / HRI4E installation HRI6E OPTIONAL LOG SET INSTALLATION OPTIONAL LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs and glass crystals may create carbon build-up and can alter the unit's performance which is not cov- ered under warranty. - Page 33 HRI6E / HRI4E installation 5. Place Log 3, rest on Log 2, match pin locator on Log 3 with landing 3. Place Log 1 on Rear Log Bracket in front of tabs, ensure Log is pin on Log 1. Angle the longest point on Log 3 is approximately 1/4' centered.
- Page 34 HRI6E / HRI4E installation 8. Place Log 6 - rest on Log 3 as shown below. Position Log 6 9. Place Log 7 on the glass as shown below. Position Log 7 10. Place embers and Lava rocks on the glass as shown below. Note: Properly positioned, Logs 3 &...
-
Page 35: Lri6E Log Set Installation
LRI6E installation LRI6E LOG SET INSTALLATION LOG INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. *For Touch Ups: Satin Black paint is included for burner, and Dark Brown Paint is included for log set, Rear Centre Log Left Side Log... - Page 36 LRI6E installation LOG INSTALLATION Log 3 in position Log 5 in position 6. Place Log 4 on the burner in the location shown below. 8. Line locator at top of Log 6 with provision on Log 1 - the locator at the bottom of Log 6 should line up with the provision on Log 5.
-
Page 37: Standing Pilot & Heat Exchange Return/Flue Restrictor
installation STANDING PILOT AND HEAT EXCHANGE RETURN/FLUE RESTRICTOR ADDING THE HEAT EXCHANGER RETURN/FLUE The LRI6E / HRI6E use a heat exchanger and efficient combustion technol- RESTRICTOR ogy to provide extreme heating efficiencies. The more efficient an appliance becomes, the lower the flue gas temperatures becomes. On start-up, flue temperatures are required to initiate venting action. -
Page 38: Brick Panel Installation
installation BRICK PANEL INSTALLATION BRICK PANEL INSTALLATION Brick panels are soft and fragile. Use caution when handling the panels, Exhaust Baffle being careful not to jar them or scratch the painted surfaces. Firebox Liner Rear Firebox Liner Right Firebox Liner Left Firebox Liner Left Upper Left of Firebox Diagram 1... -
Page 39: Enamel/Steel Panel Installation
HRI6E / HRI4E installation ENAMEL/STEEL PANEL INSTALLATION ENAMEL PANEL INSTALLATION 1. Remove filler sections from right and left sides of the burner and discard Before you Start: - see below. Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation. -
Page 40: Glass Door Removal / Installation
installation GLASS DOOR REMOVAL / INSTALLATION WARNING: Do not operate the appliance with the glass panels removed, cracked or broken. Replacement of the glass panels should be done by a licensed or qualified service person. 1) Insert the door tool into the lower door latch. Window Clip (x4) Door Frame Glass Gasket Retainer Window Glass Gasket Door Latch Door Tool Window Glass 2) Pull forward until the lower door latch is disengaged from the door frame. Door Components 3) Push downward until the Lower Door Latch is below the Door Frame. -
Page 41: Vignette Faceplate With Safety Screen Installation
installation VIGNETTE FACEPLATE VIGNETTE FACEPLATE WITH SAFETY SCREEN INSTALLATION VIGNETTE FACEPLATE W/ SAFETY SCREEN INSTALLATION Black Chrome Handling Instructions All hand and finger marks MUST be cleaned off with a soft cloth. Use an ammonia based cleaner (ie. glass cleaner) to remove any finger prints before applying heat to the unit. -
Page 42: Inlay Installation
installation INLAY INSTALLATION INLAY INSTALLATION 1. Remove Vignette faceplate from unit and lay on a soft surface. 3. Position the inlay face down on the back of the Vignette faceplate and reinstall the safety screen assembly (reverse Step 2). tooltip Inlay Vignette Faceplate (back) -
Page 43: Sided Faceplate With Safety Screen Installation
installation 4 SIDED FACEPLATE WITH SAFETY SCREEN INSTALLATION 1. Install the outer faceplate and secure with 5 screws as shown. 2. Install the outer faceplate by hooking the flange over the hanger as shown. | 43 LRI6E / HRI6E-11 Direct Vent Gas Insert... -
Page 44: Spacer Installation
installation 4E/6E SPACER INSTALLATION SPACER INSTALLATION 1. Remove Vignette faceplate from unit and lay on a soft surface. 4. Place the spacer on a soft cloth on the floor. Lay the outer faceplate over the spacer and line up the 7 holes. Attach the 3 piece spacer to the back of the outer faceplate from the front with 7 screws (3 along the top and 2 on each side). -
Page 45: Backing Plate Installation
installation 4E/6E BACKING PLATE INSTALLATION BACKING PLATE INSTALLATION 1. Remove Vignette faceplate from unit and lay on a soft surface. 3. Attach the backing plate to the outer faceplate from the front with 7 screws (3 along the top and 2 on each side). 4. -
Page 46: Optional Arched Vignette Faceplate Installation
installation LRI6E / HRI6E / LRI4E / HRI4E OPTIONAL ARCHED VIGNETTE FACEPLATE OPTIONAL ARCHED VIGNETTE FACEPLATE INSTALLATION tooltip 1. Shut off unit and allow to return to room temperature 5. Install the outer Vignette frame onto the inner Vignette frame by hanging Note: The remote control receiver located on the lower left hand side of the tabs into slots on inner Vignette frame. -
Page 47: Optional Spacer Installation
tooltip installation LRI6E / HRI6E / LRI4E / HRI4E OPTIONAL SPACER OPTIONAL SPACER INSTALLATION 1. Shut off unit and allow to return to room temperature tooltip 5. Install the outer Vignette frame onto the inner Vignette frame by 2. From the back of the spacer install the 3 pieces of the spacer to the hanging tabs onto inner Vignette frame. -
Page 48: Optional Backing Plate Installation
installation LRI6E / HRI6E / LRI4E / HRI4E OPTIONAL BACKING PLATE OPTIONAL BACKING PLATE INSTALLATION 1. Shut off unit and allow to return to room temperature 4. When using the backing plate without the spacer -- attach the tooltip backing plate with 8 screws (from the back of the backing plate). 2. -
Page 49: Optional Mantel Deflector Installation - Vignette
installation 4E/6E OPTIONAL MANTEL DEFLECTOR INSTALLATION MANTEL DEFLECTOR INSTALLATION NOTE: A mantel deflector may be installed to reduce the minimum 4. Install the mantel deflector in between the back of the outer face- mantel height. Refer to the instruction manual for minimum plate and the front of the backing plate. -
Page 50: Optional Hearth Trim Installation
LRI4E/HRI4E/LRI6E/HRI6E/E33 operating instructions OPTIONAL HEARTH TRIM INSTALLATION OPTIONAL HEARTH TRIM INSTALLATION - VIGNETTE FACEPLATE WITH SPACER VIGNETTE FACEPLATE WITH SPACER AND LOW PROFILE FACEPLATE Customizing the Hearth Trim: 5) Secure the hearth trim with a clip on its side to keep it steady as shown in the diagram below . The Hearth Trim can be adjusted to custom fit an installation by pulling apart the top piece from the bottom piece. Minimum height of the hearth trim is 2” and can be adjusted up to maximum 6”. 1) Cut the top of the bottom piece of the hearth trim to the appropriate height using a metal cutting blade. Clip - secures hearth trim NOTE: The tab bends at the back of the top piece of the hearth trim should be used as the measuring point to the hearth to measure the height required. -
Page 51: Operating Instructions
operating instructions LRI4E/HRI4E/LRI6E/HRI6E/E33 OPERATING INSTRUCTIONS OPTIONAL HEARTH TRIM INSTALLATION - Before operating this appliance, proceed through the following check list. VIGNETTE FACEPLATE WITHOUT SPACER 1) Read and understand these Instructions before operating this appliance. Customizing the Hearth Trim 2) Check to see that all wiring is correct and enclosed to prevent possible shock. The Hearth Trim can be adjusted to custom fit an installation by pulling apart the top piece from the bottom piece. Minimum height 3) Check to ensure there are no gas leaks. -
Page 52: Lighting Procedure
operating instructions LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has several options for starting/operating the appliance using the power button 3. After approximately 4 seconds the spark ignition system will spark for 60 and ON/OFF key on the hand held transmitter. seconds to light the main burner. -
Page 53: Copy Of Lighting Instruction Plate
Blower: l'information fournie avec cet appareil. Pour obtenir de l'aide ou des informations supplémen- Regency gas appliances use high tech blowers taires consulter un installateur qualifié, une agence de service ou fournisseur de gaz. to push heated air farther into the room. It is not A) This appliance is equipped with an ignition device which automatically lights the pilot. -
Page 54: Maintenance Instructions
GUARD REMOVED FOR SERVICING AN and louvers with a damp cloth. Never use an Regency dealer only, and follow our step-by-step APPLIANCE MUST BE REPLACED PRIOR abrasive cleaner. The gold louvers (and optional instructions for replacement. -
Page 55: Pilot Adjustment
Ignitor liner, and subsequently dripping out the joints, Continuous condensation can cause corrosion Note: If you have an incorrect flame pattern, of caps, pipe, and fittings. It may be caused contact your Regency dealer for further ® by having excessive lateral runs, too many instructions. elbows, and exterior portions of the system being exposed to cold weather. -
Page 56: Glass Crystal Burner Removal / Installation - Hri6E
maintenance GLASS CRYSTAL BURNER REMOVAL / INSTALLATION (HRI6E) GLASS BURNER INSTALL Disconnect unit from gas supply and allow unit to cool before removing burner. GLASS BURNER REMOVAL 1) Lift the burner assembly with both hands. Point the mixing tube towards the rear of the firebox. -
Page 57: Lri6E Ceramic Burner Removal / Installation
maintenance LRI6E CERAMIC BURNER REMOVAL / INSTALLATION INSTALLATION REMOVAL 1) Remove left and right side panels by sliding them forward - see below. Care must be taken when installing the burner into the firebox. Do not damage, knock or scrape the pilot assembly. The flame sensor and ignition lead are fragile and can be damaged easily. -
Page 58: Fan Maintenance - With Gtmf Remote Control
maintenance FAN MAINTENANCE - WITH GTMF REMOTE CONTROL Note: To access the side and rear access panels both the gas and venting 4) Remove 3 screws and remove the fan from the unit as shown below. will need to be disconnected(see vent/flue installation in this manual) for proper removal. -
Page 59: Valve Replacement
maintenance VALVE REPLACEMENT Before you begin: 5) Disconnect the Pilot Supply Line from the Gas Valve * Shut off the gas supply to the unit. Disconnect all electrical supply to the unit. Always let the appliance cool to room temperature before servicing. Remove unit flue collars. - Page 60 maintenance 11) There is a provision in the Valve body casting that is designed to be 8) Remove the Gas Valve by lifting upwards and outwards. used as a gripping point for assembly with other components. This is the portion of the valve that can be placed in a machine vice. 9) Secure the Valve Assembly by the 90 Elbow Fitting in a sturdy table vice.
-
Page 61: Gas Maintenance
Gas Maintenance GAS MAINTENANCE - RECOMMENDED ANNUAL ROUTINE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) •... -
Page 62: Main Assembly
parts list MAIN ASSEMBLY Part # Description Part # Description 940-372/P Window Glass 396-031 Bracket Valve Mounting Lh/Rh 911-085 Valve LP 885 SIT IPI 0.885.002 936-159 Window Gasket (per ft. - 9ft. required) 911-084 Valve NG 885 SIT IPI 0.885.002 396-042f Slide / Door Tool 299-574/P... - Page 63 parts list | 63 LRI6E / HRI6E-11 Direct Vent Gas Insert...
-
Page 64: Vignette Faceplate
parts list VIGNETTE FACEPLATE Part # Description Not Shown 299-811 Vignette Door Inlay Tuscan Sunset 299-825 Backing Plate Vignette Small 299-812 Vignette Door Inlay Black Chrome 299-826 Backing Plate Vignette Regular 299-813 Vignette Door Inlay Metallic Black 299-827 Backing Plate Vignette Oversize 299-814 Vignette Craftsman Inlay Tuscan Sunset 299-818... -
Page 65: Arched Vignette Faceplate
parts list ARCHED VIGNETTE FACEPLATE Part # Description Part # Description 904-790 Magnet Round 1/2" x 1/8" (Each) Midplate 299-840 Spacer Assembly Frame Vertical w/o Cutout (right) 299-843 Arched Front and Screen Assembly Edge Trim - No Break Away 299-845 Decorative Arched Front and Screen Frame Rolled Horizontal Assembly... -
Page 66: Warranty
FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: February 2019 Regency Gas Products Warranty 66 | LRI6E / HRI6E-11 Direct Vent Gas Insert... - Page 67 Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: February 2019 Regency Gas Products Warranty | 67 LRI6E / HRI6E-11 Direct Vent Gas Insert...
- Page 68 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 69 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 72 Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ HZI540 Product Video LRI6E Product Video Printed in Canada Regency and Regency Horizon, are trademarks of FPI Fireplace Products International Ltd. ® © Copyright 2020, FPI Fireplace Products International Ltd. All rights reserved.
