- Page 1 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference. CFDNH2218AS English For questions about features, operation/performance, parts or service,call: 1-800-356-5268...
-
Page 2: Table Of Contents
Contents Brief Introduction ..............................01 Important safety instructions........................... Installing your new appliance........................... Description of the appliance..........................Display controls................................Using your appliance.............................. Cleaning and care..............................Helpful hints and tips............................... Troubleshooting................................Disposal of the appliance............................ -
Page 3: Brief Introduction
Brief introduction Thank you for your choosing Crosley. We are sure you will find your new refrigerator a pleasure to use. Before you use the appliance, we recommend that you carefully read through these instructions, which provide details about installing and using the product. - Page 4 Brief introduction Warning Connect to potable water supply only. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
-
Page 5: Important Safety Instructions
Important safety instructions General safety and daily use It is important to use your appliance safely. We recommend that you follow the guidelines below. Store any food in accordance with the storage instructions from the manufacturer. Don't try to repair the appliance yourself. It is dangerous to alter the specifications or modify this product in any way. - Page 6 Important safety instructions Electrical safety To avoid the risks that are always present when using an electric appliance, we recommend that you pay attention to the instructions about electricity below. Unpack and check through the appliance. Should any damage be evident, don't plug in the appliance but contact the shop immediately from which you purchased it.
- Page 7 Important safety instructions Electrical safety Make sure that the plug is not squashed or damaged. Otherwise, it may cause short circuit, electric shock or overheat and even cause a fire. Do not insert the power plug if the socket is loose, there is a risk of electric shock or fire.
- Page 8 Important safety instructions Refrigerant The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance. During transportation and installation of the appliance, ensure that none of the components of the refrigerant circuit become damaged. The refrigerant (R600a) is flammable. Caution: Risk of Fire Don't store products which contain flammable propellants (e.g.
-
Page 9: Installing Your New Appliance
Installing your new appliance Before using the appliance for the first Ventilation of appliance time, you should be aware of the following tips. In order to improve efficiency of the cooling system and save energy, it is necessary to maintain Warning good ventilation around the appliance for the dissipation of... - Page 10 Installing your new appliance Before using the appliance for the first Leveling of appliance time, you should be aware of the For sufficient leveling and air following tips. circulating in the lower rear section of the appliance, the bottom feet may need to be adjusted.
- Page 11 Installing your new appliance Door Removal 2. Separate the two connectors on In case your home access door is too the left side door. To remove the wire narrow for the refrigerator to pass connector, press the top of the through, remove the refrigerator connector and separate it from the doors and drawers.
- Page 12 Installing your new appliance 4. Use both hands to open the door Disassembling the freezer door more than 90°. Lift it up and take it 1. Pull out the freezer door and the off. upper freezer drawer to the final position.
- Page 13 Installing your new appliance 3. Take out the upper freezer drawer 5. Remove the lower freezer drawer by lifting it up from the rail system. by lifting it up. Upper freezer Lower freezer drawer drawer 6. Remove 2 screws holding the 4.
- Page 14 Installing your new appliance 7. Remove the freezer door by lifting Warning it up Freezer door The water connection must be made by a qualified plumber. Operation outside the water pressure range may cause malfunction, severe and damaging water leaks. Under normal conditions, a200cc (5.75 oz.) cup can be filled in about 10 seconds.
- Page 15 Installing your new appliance 3. Connect 1/4’’ extension tubing to 4. You need to purchase several item shutoff valve outlet. to complete this connection. You may find these items sold as a kit at local hardware store Connecting to the water supply Saddle-Type Shutoff Valve Compression Nut line...
- Page 16 Installing your new appliance Note Note After connected to the water Ensure that the water line does supply line, please open the water not get pinched or bent when valve to flush the filter for 5 minutes installing. before use. The initial dark This can result in improper water discoloration of water is normal.
- Page 17 Installing your new appliance 5. Insert the free end and of the 1/4" Connect Water Line to Refrigerator water line into the brass fitting IMPROTANT: If you turn the refrigerator attached to the water inlet on the on before the water is connected, turn back of the refrigerator.
-
Page 18: Description Of The Appliance
Description of the appliance Ice maker Door rack Vertical baffle part Water and ice dispenser (inside) Fruit and vegetables crisper Multi-function drawer Freezer LED light Middle freezer drawer Lower freezer drawer Adjustable bottom feet Top cover Vertical baffle guide block Water filter Refrigerator LED light (inside) Glass shelf... -
Page 19: Display Controls
Display controls Your product has one control panel which is installed on the fridge door. Use your appliance according to the following control guidelines. When the appliance is powered on for Note the first time, the backlighting of the icons on the display panel start working. When you set a temperature, you If no buttons have been touched or the set an average temperature for... - Page 20 Display controls 2. Door Alarm Fridge temperature control Leaving any door open for over 2 minutes will activate door alarm. The You can touch the “Fridge” icon to icon " " will flicker, the control panel will activate the mode to control the fridge display "dr", and you will hear a buzzer temperature.
- Page 21 Display controls seconds, the Super Freeze icon " " Note will be illuminated, the freezer temperature setting displays -11°F On the Super Cool Function, when (-24°C). Super Freeze can quickly you touch the "Eco" button, "Eco" lower the temperature and freeze function will be activated, and your food faster than usual.
- Page 22 Display controls °F/°C When the Child Lock is off, you can touch You can touch this button to turn Eco the " " icon to switch between Celsius mode on and off. When you turn Eco and Fahrenheit units. The default state is on, the Eco icon "...
- Page 23 Display controls Wi-Fi function Step 2: Touch the Fridge key to select 'O' This appliance may be controlled within 60 seconds. remotely with a smart phone or a tablet Step 3: Touch the Wi-Fi icon to confirm computer. If the appliance is not the selection mode.
- Page 24 Display controls Step 4: When the display returns to Information! normal, it means the PAIR connection We recommend downloading and installing the mobile app and creating is successful. a ConnectLife account before attempting to set up the connection with your appliance. ConnectLife App The ConnectLife App is available to download free of charge from the...
- Page 25 Display controls 4. Select ‘SET UP APPLIANCE’, follow the User manual: instruct and make sure Wi-Fi function • As the application continues to be of the appliance is activated, then upgraded, please refer to the actual select 'Next'. display interface. Note: When the appliance has connected to the home network and Transmitting frequency band(s) and...
-
Page 26: Using Your Appliance
Using your appliance This section tells you how to use most Suggested position of the useful features. We recommend that you read through them carefully About 50mm before using the appliance. Getting Cold Water and Ice The water dispenser is located in the fridge door. - Page 27 Using your appliance Changing the water filter Note To drink the freshest and cleanest water from your refrigerator, change To change the water filter easily, the filter on time. To change the shut off the water supply valve. water filter, follow these steps: Sometimes, it is hard to disassemble the water filter 1.
- Page 28 Using your appliance 5. If you turned off the water supply, Note turn it back on. Be sure to flush the dispenser Note thoroughly, otherwise water may drip from the dispenser. This After turning on the water supply, means that there is still air you should check the leaks.
- Page 29 Using your appliance If your refrigerator has a water filter, it may further reduce the water pressure when used in conjunction with a reverse osmosis system. To resolve it, remove the water filter. Using your fridge compartment The refrigerator compartment is suitable for storage of vegetables Glass shelves and fruit.
- Page 30 Using your appliance The refrigerator compartment is also Ice Maker in Refrigerator provided with a foldable shelf. It can Press “Ice Off” Button to turn the ice be folded as required. maker On and Off. The Ice Off icon “ ”...
- Page 31 Using your appliance To remove the ice bucket Caution 1. Gently lift it up, and then pull it out slowly while holding the bottom of the Do not apply excessive force to bucket with one hand and the side the bucket cover. The cover may with the other hand.
-
Page 32: Cleaning And Care
Cleaning and care For hygienic reasons the appliance Caution (including exterior and interior accessories) should be cleaned at Don’t use sharp objects to clean least every two months. with, as they are likely to scratch the surface. Warning Don’t use thinner, car cleaner, bleach, oil, abrasive cleansers or organic solvent such as benzene To avoid electrical shock, the... - Page 33 Cleaning and care Door seals cleaning Although this appliance automatically defrosts, a layer of frost Take care to keep door seals clean. may occur on the freezer Sticky food and drinks can cause seals compartment’s interior walls if the to stick to the cabinet and tear when freezer door is opened frequently or you open the door.
-
Page 34: Helpful Hints And Tips
Helpful hints and tips Energy saving tips Hints for refrigeration We recommend that you follow the For Meat: (all types) wrap in cling tips to save energy. wrap and place on the glass shelf Try to avoid keeping the door open above the vegetable drawer. - Page 35 Helpful hints and tips Switching off your appliance Do not allow unfrozen food to touch the food which is already frozen to If the appliance needs to be avoid temperature rise of the latter. switched off for an extended period, the following steps should be taken Iced products (ice cubes, popsicles): to prevent mould on the appliance.
-
Page 36: Troubleshooting
Troubleshooting If you experience a problem with your appliance or are concerned that ine appliance is not functioning correctly, you can carry out some easychecks before calling for service, please see below. You can carry out someeasy checks according to this section before calling for service. Warning 1. - Page 37 Troubleshooting Problem Possible Cause & Solution The interior may need to be cleaned. Odours from the compartments Some food, containers or wrapping cause odours. The sounds below are quite normal: Compressor running noises. Air movement noise from the small fan motor in the freezer compartment or other compartments.
- Page 38 Troubleshooting Problem Possible cause & Solution You may have left the doors open too long or too frequently; Temperature Or the doors are kept open by some obstacle; inside is too Or the appliance is located with insufficient clearance at warm the sides, back and top.
- Page 39 Troubleshooting Problem Possible cause & Solution Did you wait for 12 hours after installation of the water supply line before making ice? If it is not sufficiently cool, it may take longer to make ice, such as when first installed. Is the water line connected and the water valve open?Did you manually stop the ice making function? Make sure you do not set the “Ice Off”...
-
Page 40: Disposal Of The Appliance
Disposal of the appliance It is prohibited to dispose of this appliance as household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. Before disposal of the appliance 1.
