8 TECHNICAL SPECIFICATIONS
Technical Specifications Table
Frequency Band
RF Power
Output power accuracy
Antenna
Frequency Tolerance
Number of Channels
Standard Compliance
User Interface
Connectivity
Dimensions
Electrical Power
Operating Temperature
Weight
Length of USB cable
Tab. 8.1: Tile R1250I Technical Specifications
Warning: The RF settings must match the operating country/region to comply with local laws
and regulations.
The usage of the reader in different countries/regions from the one in which the device has
been sold is not allowed.
TECHNICAL SPECIFICATIONS - Tile R1250I - Technical Information Manual
865.600÷867.600 MHz (ETSI EN 302 208) (Mod. R1250IE)
902÷928 MHz (FCC part 15) (Mod. R1250IU)
Programmable in 18 levels (1dB step) from 8 dBm ERP to 25 dBm
ERP (Mod. R1250IE)
Programmable in 18 levels (1dB step) from 8.5 dBm ERP to 25.5
dBm ERP (Mod. R1250IU)
+/- 1dB
Integrated Circular Polarized Antenna
±10 ppm over the entire temperature range
4 channels (compliant to ETSI EN 302 208 v.3.1.1) (Mod.R1250IE)
50 hopping channels (compliant to FCC part 15.247) (Mod.R1250IU)
EPC C1G2/ISO 18000-6C
Red LED: Power Blinking
Green LED: Tag detection
Mini USB type B plug connector
USB 2.0 Full Speed (12Mbit/s) device port
Must be connected to two High-power USB Type A ports (500 mA @
VBUS)
Virtual COM port parameters:
- Baudrate: up to 115.200kbps
- Databits: 8
- Stopbits: 1
- Parity: none
- Flow control: none
HID profile available
(W)125 x (L)125 x (H)25 mm
3
3
(4.92 x 4.92 x 0.98 inch
)
5 V ± 5% - DC bus powered (USB)
Max 650 mA
-10 °C to +55 °C
220g max.
1 m
28
