3 CONFIGURATION MENU
Introduction
The Tile R1250I reader is detected by the PC as two emulated serial ports:
•
Virtual COM Port
•
Config COM Port
The Config COM Port is used to configure the reader profile.
The Virtual COM Port is the main communication interface.
Reader Configuration Menu
1.
Verify that the Y USB cable provided with the reader is correctly plugged into the PC
2.
Install the required CAEN RFID USB driver as explained in § Driver installation page 11.
3.
Open a serial terminal compatible with VT100 (e.g. Hyperterminal or Teraterm).
4.
Click on File-> New Connection and look for the R1250I Config Port (in the example COM5) and select
it. Press the OK button.
5.
Press the "ESC" key to access the reader configuration menu:
CONFIGURATION MENU - Tile R1250I - Technical Information Manual
15
