7 FIRMWARE UPGRADE
The Tile R1250I firmware upgrade can be managed via USB. You need the Tile Upgrade Tool and the R1250I
firmware image available for free at the
Firmware
area.
To upgrade the firmware, follow the steps described below:
1.
Remove the 4 screws on the back of the reader case (see the picture below).
2.
Connect to the USB port the evaluation board with the Quark Up reader installed (the R1270CEVB
evaluation board is the one circled in red in following picture).
3.
Press the reset switch on the evaluation board (SW3).
4.
With SW3 pressed, press the BSL_SEL switch on the evaluation board (SW2).
FIRMWARE UPGRADE - Tile R1250I - Technical Information Manual
Tile R1250I web
page, Downloads section or in
Software &
25
