4 EASY2READ PROFILE
Introduction
By default, the reader is in the easy2read profile.
With the EASY2READ profile active you will use the CAEN RFID easy2read communication protocol and the
reader can be controlled using the
Development Kit)
If your reader is in the HID profile active, to set the EASY2READ profile, please refer to § Active
Profile paragraph page 16.
Connecting the Tile R1250I Reader using the
EasyController
Using the EASY2READ profile, you can connect to the Tile R1250I Reader using the EasyController software
via USB connection.
1.
Download the latest version of the EasyController software for Windows from the
page, Downloads section and install it.
2.
Verify that the Y USB cable provided with the reader is correctly plugged into the PC
3.
Install the required CAEN RFID USB driver as explained in § Driver installation page 11.
4.
Once the serial port connection is established, CAEN RFID EasyController software can be used to
interface the reader. Launch the EasyController by double clicking on the icon on your desktop:
5.
Click on File → Connect, select the RS232 Connection Type and select from the pull-down menu the
COM port number where the driver has mapped the virtual port for the Tile (in the example COM4)
and then click on connect.
EASY2READ PROFILE - Tile R1250I - Technical Information Manual
CAEN RFID Easy Controller Application
library.
or the
SDK (Software
Tile R1250I
web
19
