If you have set the HID profile, after 6 seconds the device starts making inventories and transferring the
EPC codes to the host PC through the HID interface.
You can activate only one profile at a time.
Startup RF Power
The Startup RF Power can be set in both easy2read HID profile.
The reader is sold with the factory Startup RF Power set to 200mW.
To set a different RF value, press the down arrow and then the right arrow to select the Startup RF Power
value. Using the "backspace" key, delete the current value and insert the desired power value in the range
0-500. All values are expressed in mW.
Press the ESC key to exit from the configuration interface and to save the new setting.
The display shows the message "Configuration Saved" to inform you that the new settings is active.
Disconnect the USB cable and connect the reader once again.
You can activate only one power level at a time.
HID Keyboard
The HID Keyboard options are the following:
•
QWERTY: standard keyboard.
•
AZERTY: French keyboard
The reader is sold with the factory HID keyboard set to QWERTY.
To set a different keyboard, press the down arrow until "HID Keyboard" is displayed and then the right
arrow to select the QWERTY option; use the "-" or "+" keys to shift between QWERTY and AZERTY. Press
the ESC key to exit from the configuration interface and to save the new setting.
The display shows the message "Configuration Saved" to inform you that the new settings is active.
Disconnect the USB cable and connect the reader once again.
You can activate only one HID Keyboard at a time.
HID format
In the HID profile you can set different EPC format, while using the EASY2READ profile it is not possible to
change the HEXADECIMAL EPC format.
The HID format options are the following:
•
HEXADECIMAL: The RFID EPC is represented by hexadecimal digits
•
ASCII: The RFID EPC is represented by ASCII characters
•
SGTIN14: This is a special option, please contact our
The reader is sold with the factory HID format set to HEXADECIMAL.
To set a different format, press the down arrow until "HID format" is displayed and then the right arrow to
select the HEXADECIMAL option (factory format); use the "-" or "+" keys to select the desired format. Press
the ESC key to exit from the configuration interface and save the new setting.
The display shows the message "Configuration Saved" to inform you that the new settings is active.
Disconnect the USB cable and connect the reader once again.
You can activate only one HID format at a time.
HID inter-line delay
The Inter-line delay is the delay between printing the last character of a line and the first character of the
next line. It is expressed in ms. The default value is 0 and the reader does not introduce delay.
To set a different Inter-line delay, press the down arrow until "HID Inter-line delay" is displayed and then
the right arrow to select the current value. Using the "backspace" key, delete the current value and insert
the desired Inter-line delay in the range 0÷31999.
CONFIGURATION MENU - Tile R1250I - Technical Information Manual
support team for more info
