- Page 1 Products Solutions Services BA00416C/07/EN/18.22-00 71596229 2022-10-31 Operating Instructions OUSAF44 Optical sensor with the OUA260 flow assembly for the measurement of UV absorption...
-
Page 3: Table Of Contents
OUSAF44 Table of contents Table of contents About this document ... 4 Repair ......34 Warnings . -
Page 4: About This Document
About this document OUSAF44 About this document Warnings Structure of information Meaning This symbol alerts you to a dangerous situation. DANGER Failure to avoid the dangerous situation will result in a fatal or serious injury. Causes (/consequences) If necessary, Consequences of non- compliance (if applicable) ‣... -
Page 5: Basic Safety Instructions
OUSAF44 Basic safety instructions Basic safety instructions Requirements for the personnel • Installation, commissioning, operation and maintenance of the measuring system may be carried out only by specially trained technical personnel. • The technical personnel must be authorized by the plant operator to carry out the specified activities. -
Page 6: Product Safety
Basic safety instructions OUSAF44 Ensure that electrical cables and hose connections are undamaged. Do not operate damaged products, and protect them against unintentional operation. Label damaged products as defective. During operation: ‣ If faults cannot be rectified: products must be taken out of service and protected against unintentional operation. -
Page 7: Product Description
OUSAF44 Product description Product description Sensor design A0030202 1 Sensor with flow assembly OUA260 Cable connector Lamp module Flow assembly OUA260 (depending on version) Detector module The detector and lamp can vary on account of the individual options ordered. -
Page 8: Measuring Principle
Product description OUSAF44 Measuring principle Light absorption The measuring principle is based on the Lambert-Beer law. There is a linear dependency between the absorption of light and the concentration of the absorbing substance: A = -log(T) = ε T = I/I T ... -
Page 9: Incoming Acceptance And Product Identification
OUSAF44 Incoming acceptance and product identification Incoming acceptance and product identification Incoming acceptance Verify that the packaging is undamaged. Notify the supplier of any damage to the packaging. Keep the damaged packaging until the issue has been resolved. Verify that the contents are undamaged. -
Page 10: Manufacturer Address
If you have any queries: Please contact your supplier or local sales center. Mounting Mounting requirements 5.1.1 Measuring system An optical measuring system comprises: • Sensor (photometer) OUSAF44 • Transmitter, e. g. Liquiline CM44P • Cable set, e. g. CUK80 • Assembly OUA260 Endress+Hauser... - Page 11 OUSAF44 Mounting 3 Example of a measuring system with a photometer sensor Pipe Flow assembly OUA260 Transmitter CM44P Sensor: light source (lamp) CUK80 cable set CUK80 cable set Sensor: detector Endress+Hauser...
- Page 12 Mounting OUSAF44 5.1.2 Dimensions A0028305 4 Sensor module Dimension of lamp → Table Dimension of detector → Table Assembly, see Technical Information for assembly Lamp type Dimension A in mm (inch) Mercury vapor lamp 142 (5.60) Detector type Dimension B in mm (inch) Standard with reference rod 60.2 (2.37)
-
Page 13: Mounting The Sensor
OUSAF44 Mounting 5.1.3 Mounting bracket A0028250 5 Mounting angles. The arrows indicate the direction of medium flow in the pipe. Suitable mounting angle, better than C Optimum mounting angle, best installation position Acceptable mounting angle Mounting angle to be avoided... -
Page 14: Post-Mounting Check
Electrical connection OUSAF44 ‣ Install the sensor upstream from the pressure regulators. ‣ Leave enough room for the cable connector at the end of the lamp and at the end of the detector housing. Unimpeded access to these areas is also required for connection/removal tasks. -
Page 15: Connecting The Sensor
The cable set must be ordered separately. ‣ Do not shorten or otherwise modify the CUK80 cable! A0028385 6 OUSAF44 connecting cable Light source (lamp) power supply Signals of measurement and reference detector CM44P terminal Cable color... -
Page 16: Versions For Use In Hazardous Areas
Electrical connection OUSAF44 Versions for use in hazardous areas Section applies only to measuring points consisting of a photometer, cable set CUK80 and a Liquiline CM44P transmitter. Safety instructions for electrical apparatus in explosion-hazardous areas, XA01403C 6.3.1 Connecting the detector using a safety barrier The photometer sensors use silicon photovoltaic cells as detectors which are operated in the current mode. - Page 17 OUSAF44 Electrical connection On delivery, the CUK80 detector cable is permanently wired to the safety barrier. All you have to do is simply connect the individual cable ends to the detector and transmitter. Mount safety barrier including grounding module on a DIN rail.
-
Page 18: Ensuring The Degree Of Protection
Electrical connection OUSAF44 EXP 1 Transmitter ATEX II 2G Ex db IIC T5 Gb FM Cl.1, Div. 1, Groups B, C, D A (2) C (2) SH (2) A0029441 8 Connecting the hazardous area lamp to CM44P via a junction box... -
Page 19: Post-Connection Check
OUSAF44 Electrical connection Post-connection check Device condition and specifications Notes Are the sensor, assembly and cable free from damage on the outside? Visual inspection Electrical connection Notes Does the supply voltage of the connected transmitter match the data on the... -
Page 20: Commissioning
Commissioning OUSAF44 Commissioning Function check Prior to initial commissioning, ensure that: • The sensor is correctly installed • The electrical connection is correct Calibrating/adjusting the sensor Measuring points consisting of a photometer sensor, flow assembly (if provided) and a transmitter are adjusted at the factory. Normally adjustment is not required when commissioning for the first time. - Page 21 OUSAF44 Commissioning While the D-tryptophan is dissolving, add deionized water until the beaker contains an approximate volume of 450 ml. Continue stirring at 30 °C (86 °F) until the tryptophan is completely dissolved. Dilute the solution to 1000 ml in a volumetric flask.
- Page 22 Commissioning OUSAF44 It is very important that you use the actual values of the optical Easycal filter. These values are given in the calibration certificate supplied. ‣ Enter the absorbance values (CM44P): Menu/Setup/Inputs/Photometer/Extended setup/Measurement channel/Calib. settings/EasyCal = Yes, NIST filter high and NIST filter low.
-
Page 23: Maintenance
OUSAF44 Maintenance Maintenance Take all the necessary precautions in time to ensure the operational safety and reliability of the entire measuring system. NOTICE Effects on process and process control! ‣ When carrying out any work on the system, bear in mind any potential impact this could have on the process control system and the process itself. - Page 24 Maintenance OUSAF44 CAUTION Mercury lamp Can cause damage to the eyes and skin! ‣ Avoid any exposure of the eyes and skin to the unshielded product. ‣ Wear suitable protective goggles to protect against UV radiation. Removing the used lamp ‣...
- Page 25 OUSAF44 Maintenance Hold the lamp socket in the gap between the lamp power supply unit and the reflector and press it out of its fitting. Do not damage the cable of the circuit board! Then press the lamp out completely through the reflector.
-
Page 26: Replacing The Reference Filter
Maintenance OUSAF44 Retighten the securing screw. This screw is only used to hold the lamp in position. Therefore, do not tighten it too tightly as to do so could damage or break the lamp. Make sure that the lamp contact area is completely clean and dry before re-closing. - Page 27 OUSAF44 Maintenance CAUTION Mercury lamp Can cause damage to the eyes and skin! ‣ Avoid any exposure of the eyes and skin to the unshielded product. ‣ Wear suitable protective goggles to protect against UV radiation. ‣ Switch off the lamp using the software function on the transmitter.
-
Page 28: Replacing The Measurement Filter
Maintenance OUSAF44 In addition, you must reset the counter for filter replacement in the case of the CM44P: CAL/ Photometer/Filter change/Reset Replacing the measurement filter Versions with Easycal: If the Easycal detector module is sent in for recertification, a diagnostic scan of the measurement filter is performed and the measurement filter is replaced if necessary. - Page 29 OUSAF44 Maintenance Hold the assembly in a vertical, upright position and tap against it gently until the filter falls out. Insert the new measurement filter into the housing. The arrow on the filter indicates the direction of installation. Insert the filter into the housing with the arrow pointing down.
-
Page 30: Replacing The Sensor Window And Seal
Maintenance OUSAF44 Mount the detector housing back onto the flow assembly. You must then recalibrate/readjust the measuring system. In addition, you must reset the counter for filter replacement in the case of the CM44P: CAL/ Photometer/Filter change/Reset Replacing the sensor window and seal... - Page 31 OUSAF44 Maintenance The following description applies for both sides, i.e. the detector side and the lamp side. Always change O-rings or optical windows on both sides. Remove the 4 Allen screws (1/8" or 3 mm) from the window ring. Make sure to loosen the screws evenly and alternately around the window ring.
- Page 32 Maintenance OUSAF44 Mount the optical window and then the window ring, along with the new seals, on the assembly. Make sure to tighten the screws of the window ring uniformly in a diagonally opposite sequence. In this way, you ensure that the ring is seated correctly.
- Page 33 OUSAF44 Maintenance A0030205 13 Assembly with POPL function, sectional view Measuring gage Assembly OUA260 Screws of the window ring Path length adjuster Actuators with gaskets Securing screws The following description applies for assemblies with POPL already fitted. If you are retrofitting POPL, please refer to the instructions supplied with the spare parts kit.
-
Page 34: Repair
The product must be returned if repairs or a factory calibration are required, or if the wrong product was ordered or delivered. As an ISO-certified company and also due to legal regulations, Endress+Hauser is obliged to follow certain procedures when handling any returned products that have been in contact with medium. -
Page 35: Disposal
OUSAF44 Accessories Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste. -
Page 36: Cable
• Pre-terminated and labeled cables for connecting OUSAF4x-type sensors to Memograph CVM40 • Order as per product structure 10.3 Calibration Kit OUSAF44 EasyCal retrofit kit • Patented system traceable to NIST for the calibration of UV absorption sensors • Order numbers: • 254 nm: 71210149 • 280 nm: 71210150 •... -
Page 37: Environment
OUSAF44 Technical data 11.2 Environment 11.2.1 Ambient temperature Non-hazardous area versions 0 to 55 °C (32 to 131 °F) Hazardous area versions 2 to 40 °C (36 to 104 °F) 11.2.2 Storage temperature -10 to +70 °C (+10 to +160 °F) 11.2.3... - Page 38 Technical data OUSAF44 11.4.2 Weight Sensor UV lamp 0.58 kg (1.28 lbs) UV lamp with wire-braided cable 3.2 kg (6.66 lbs) (1.2 m (4 ft)) and junction box (sensor for hazardous area) Easycal detector 0.65 kg (1.43 lbs) Standard detector 0.36 kg (0.794 lbs)
-
Page 39: Index
