Field Name
Description
work. The default is -1 (no shaping).
Scheduler for Queues of
The algorithm used to schedule the queue behavior. VC scheduling is different than
Equal Precedence as the
the default queues. Options are:
Default Queue
Default Queue Weight
Enter a default weight of the specified queue. Options are: 1-63.
Default Queue Pre-
Enter a precedence for the specified queue. Options are: 1-8.
cedence
VC WRR Weight
The weight of the specified virtual channel queue. Options are 1-63.
VC Precedence
The priority of the specified virtual channel queue. Options are 1-8.
PTM Interface
The SmartRG gateway's VDSL2 standards support Packet Transfer Mode (PTM). An alternative to ATM mode, PTM transports packets
(IP, PPP, Ethernet, MPLS, and others) over DSL links. For more information, refer to the IEEE802.3ah standard for Ethernet in the First
Mile (EFM). Some 500 series gateways have a PTM interface configured by default.
On this page, you can configure a PTM interface for your gateway.
1. In the left navigation bar, click
appears.
SmartRG Inc., an ADTRAN company. All Rights Reserved. © 2020
Weighted Round Robin: Packets are accessed in a round robin style. Classes
l
can be assigned.
Weighted Fair Queuing: Packets are assigned to a specific queue.
l
Advanced Setup
>
Layer2 Interface
>
PTM Interface
and then click Add. The following page
24
