Connecting the External Ethernet Adapter
to Your Printer
Although you can connect the external Ethernet adapter to several
different Intermec printers, the illustrations in the following procedure
use the 7421.
To connect the Ethernet adapter
1. Note the serial number found on the underside of the Ethernet
adapter. You need this number during the configuration.
2. Turn off the printer.
3. Plug the parallel port connector into the printer's parallel port.
4. Connect a 10BaseT cable into the 10BaseT connector.
Parallel port
connector
10BaseT
10BaseT
connector
cable
Parallel
port
AXISI.003
7
