Use the following illustrations to familiarize yourself with the external
or internal Ethernet adapter.
External Ethernet Adapter
Parallel port
connector
10BaseT
connector
External
power
supply
connector
Internal Ethernet Adapter
6
+
AXISI.001
Network
LED
Power
LED
Test
button
O
10BaseT
connector
AXISI.002
Test button
Network
LED
Power
LED
