I Specifications
ï ï General
• Frequency coverage
Transmit
Receive
• Mode
• Channel spacing
• Current drain (at 13.8 V)
• Power supply requirement
• Frequency stability
• Dimensions
(Projections not included)
• Weight
ï ï Transmitter
• Output power
• Modulation system
• Max. frequency deviation
• Spurious emissions
:
156.025–157.425 MHz
156.050–163.275 MHz
: FM (16K0G3E)
DSC(16K0G2B)
: 25 kHz
: TX high 5.5 A max.
Max. audio 1.5 A max.
: 13.8 V DC
: ±10 ppm
(–20°C to +60°C; –4°F to +140°F)
: 153(W) × 67(H) × 132(D) mm
(W) × 2
1 5 3
6 ⁄ ⁄ (H)× 5 ⁄ (D) in
32 8 16
: Approx. 825 g ; 1.8 lb
: 25 W and 1 W
: Variable reactance frequency
modulation
: ±5.0 kHz
: Less than –70 dB

SPECIFICATIONS

ï ï Receiver
• Receive system
• Sensitivity (12 dB SINAD)
• Squelch sensitivity
• Intermodulation rejection ratio
• Spurious response rejection ratio: More than 70 dB
• Adjacent channel selectivity
• Audio output power
All stated specifications are subject to change without notice or
obligation.
11
: Double conversion
superheterodyne
: 0.22µV (typical)
: Less than 0.22µV
: More than 70 dB
: More than 70 dB
: 4.5W (typical) at 10%
distortion with a 4 Ω load
