- Page 1 COMPANION PRODUCTS Coffee Maker EB24 Steam Oven OS24N Speed Oven OM24N models INSTALLATION GUIDE US CA 591496G 01.21...
-
Page 2: Table Of Contents
CONTENTS Coffee maker Steam oven Speed oven Safety and warnings Safety and warnings Safety and warnings Parts supplied Prior to installation Prior to installation Prior to installation After installation After installation After installation Product dimensions Product dimensions Product dimensions 5A Cabinetry dimensions 5A Cabinetry dimensions (18 1/8"... -
Page 3: Coffee Maker
COFFEE MAKER EB24 models 560.00 20.25... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! To protect against fire, electric shock and injury to persons do not submerge the cord or ● plugs in water or other liquids. Installation To reduce the risk of injury, do not drape cord over the counter top or table top where it ●... -
Page 5: Parts Supplied
PARTS SUPPLIED Screws Rails (2) Clip (1) (28) Spacers (4) for side (4) for bottom PRIOR TO INSTALLATION The countertop and coffee maker cavity are square and level, and are the required dimensions. ● The installation will comply with all clearance requirements and applicable standards and regulations. 560.00 ●... -
Page 6: Product Dimensions
PRODUCT DIMENSIONS SIDE EB24 MODELS PRODUCT DIMENSIONS inches (mm) Overall height of product 18" (458) Overall width of product 23 1/2" (596) Overall depth of product ( 18 7/8" (480) excluding dials) Height of chassis 17 1/2" (445) Width of chassis 22 1/16"... -
Page 7: Cabinetry Dimensions (18 1/8" (460Mm) High Cavity)
CABINETRY DIMENSIONS (18 1/8" (460mm) HIGH CAVITY) Verify the minimum measurements required for correct installation of the appliance. The coffee maker must be installed in a column and the column must be firmly fixed to the wall with commercially available brackets. IMPORTANT! 5/8–13/16"... -
Page 8: Cabinetry Dimensions (18 7/8" (480Mm) Cavity Trim Kit)
CABINETRY DIMENSIONS (18 7/8" (480mm) CAVITY TRIM KIT) Verify the minimum measurements required for correct installation of the appliance. The coffee maker must be installed in a column and the column must be firmly fixed to the wall with commercially available brackets. Lower Trim Kit The Lower Trim kit shown is available to order separately from fisherpaykel.com. -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS approx. 13 3/4" (350mm) Position the rails on the sides of the cabinet. Fix with the screws provided, then extract Fix the power cable with the clip. The power cable must be long enough to allow them completely. the appliance to be extracted from the cabinet to fill the coffee bean container. -
Page 10: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the coffee maker is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Check there is adequate clearance. This is to ensure correct air circulation. Make sure any cable ties and internal packaging has been removed from the coffee maker cavity. Make sure all coffee maker vents and openings are clear and free of any obstruction or damage. -
Page 11: Steam Oven
STEAM OVEN OS24N models 556.00 565.30 22.00... -
Page 12: Safety And Warnings
SAFETY AND WARNINGS Installation If the installation requires alterations to the domestic electrical system, call a qualified ● electrician. The electrician should also check that the socket cable section is suitable WARNING! for the electricity drawn by the oven. The oven must be grounded. ●... -
Page 13: Prior To Installation
PRIOR TO INSTALLATION The countertop and oven cavity are square and level, and are the required dimensions. ● 560.00 The installation will comply with all clearance requirements and applicable standards and regulations. ● The isolating switch will be easily accessible to the customer with the oven installed. ●... -
Page 14: Product Dimensions
PRODUCT DIMENSIONS SIDE OS24N MODELS PRODUCT DIMENSIONS inches (mm) Overall height of product 18" (458) Overall width of product 23 7/16" (596) Overall depth of product (excluding handle and dials) 22 1/8" (562) Height of chassis 17 1/2" (445) Width of chassis 21 7/8"... -
Page 15: Cabinetry Dimensions (18 1/8" (460Mm) High Cavity)
CABINETRY DIMENSIONS (18 1/8" (460mm) HIGH CAVITY) The oven can be installed under a cooktop, in a column, or combined with the companion warmer drawer. ● The cabinet material must be able to withstand heat. ● The oven must be centered within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... -
Page 16: Cabinetry Dimensions (18 7/8" (480Mm) Cavity Trim Kit)
CABINETRY DIMENSIONS (18 7/8" (480mm) CAVITY TRIM KIT) The oven must be installed under a cook top, in a column, or combined with the companion warmer drawer. ● The cabinet material must be able to withstand heat. ● The oven must be centred within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... -
Page 17: Electrical Hook-Up
ELECTRICAL HOOK-UP Before connecting to the electricity, make sure that the: specifications of the electrical system match with what is detailed on this section. (Fig. 1) ● system has an effective ground connection compliant with current standards and laws. ● The ground connection is required by law. -
Page 18: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Open the oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. -
Page 19: Speed Oven
SPEED OVEN OM24N models 556.00 565.30 22.00... -
Page 20: Safety And Warnings
SAFETY AND WARNINGS Installation If the installation requires alterations to the domestic electrical system, call a qualified ● electrician. The electrician should also check that the socket cable section is suitable WARNING! for the electricity drawn by the oven. The oven must be grounded. ●... -
Page 21: Prior To Installation
PRIOR TO INSTALLATION The countertop and oven cavity are square and level, and are the required dimensions. ● 560.00 The installation will comply with all clearance requirements and applicable standards and regulations. ● The isolating switch will be easily accessible to the customer with the oven installed. ●... -
Page 22: Product Dimensions
PRODUCT DIMENSIONS SIDE OM24N MODELS PRODUCT DIMENSIONS inches (mm) Overall height of product 18" (458) Overall width of product 23 7/16" (596) Overall depth of product (excluding handle and dials) 22 1/8" (562) Height of chassis 17 1/2" (445) Width of chassis 21 7/8"... -
Page 23: Cabinetry Dimensions (18 1/8" (460Mm) High Cavity)
Electrical supply 5/8–13/16" FLUSH INSTALL (16–20mm) 7/8" (22mm) min 1/16" (2mm) SIDE OM24N MODELS CABINETRY DIMENSIONS inches (mm) Minimum inside width of cavity 22 1/16" (560) Overall width of cabinetry 23 5/8" (600) Minimum inside height of cavity 17 3/4" (450) Overall height of cabinetry 18 1/8"... -
Page 24: Cabinetry Dimensions (18 7/8" (480Mm) Cavity Trim Kit)
FLUSH INSTALL (16–20mm) 7/8" (22mm) Lower min 1/16" (2mm) SIDE Trim kit OM24N MODELS CABINETRY DIMENSIONS inches (mm) Minimum inside width of cavity 22 1/16" (560) Overall width of cabinetry 23 5/8" (600) Minimum inside height of cavity 18 1/2" (470) Overall height of cabinetry 18 7/8"... -
Page 25: Electrical Hook-Up
ELECTRICAL HOOK-UP Before connecting to the electricity, make sure that the: specifications of the electrical system match with what is detailed on this section. (Fig. 1) ● system has an effective ground connection compliant with current standards and laws. ● The ground connection is required by law. -
Page 26: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Open the oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation.
