Summary of Contents for Fisher & Paykel ELBA OR60
- Page 1 Freestanding cooker Installation instructions OR60 & OR90 models User guide NZ AU...
- Page 3 Contents Safety and warnings Installation instructions - OR60 models Installation instructions - OR90 models Using your oven Cooking functions Using your gas cooktop Cooktop troubleshooting Care and cleaning Warranty and service Important! SAVE THESE INSTRUCTIONS The models shown in this User Guide may not be available in all markets and are subject to change at any time.
-
Page 4: Safety And Warnings
Safety and warnings Installation WARNING! Electrical Shock Hazard Always disconnect the cooker from the mains electricity supply before carrying out any maintenance operations or repairs. Failure to follow this advice may result in death or electrical shock. WARNING! Cut Hazard Take care - panel edges are sharp. - Page 5 Safety and warnings The appliance must be connected to the mains electricity supply, checking that the voltage corresponds to the value given in the rating plate and that the electrical cable sections can withstand the load specified on the plate. A suitable disconnection switch must be incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations.
- Page 6 Safety and warnings Operation Your freestanding cooker has been carefully designed to operate safely during normal cooking procedures. Please keep the following guidelines in mind when you are using it: WARNING! Explosion Hazard Do not store flammable materials such as gasoline near the cooktop. Do not store flammable material in the oven, drawer or storage compartment.
-
Page 7: Important Safety Precautions
Safety and warnings Important safety precautions Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. Isolating switch: make sure this cooker is connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. Household appliances are not intended to be played with by children. - Page 8 Installation instructions Installation instructions Dimensions and clearances Installation clearances and protection of combustible surfaces shall comply with the current local regulations eg. AS/NZS 5601.1 Gas Installations code. Installation shall comply with the dimensions in Fig. 1, bearing in mind the following requirements: Overhead Clearances In no case shall the clearance above the highest part of the cooker be less than 600 mm or, for an overhead exhaust fan, 750 mm.
-
Page 9: Levelling The Cooker
Installation instructions Levelling the cooker Important! Using the supplied adjustable feet is MANDATORY. For safety reasons and to ensure adequate ventilation, the cooker chassis MUST NOT sit directly on the floor, a plinth, or other support surface. To fit the adjustable feet: Rest the rear of the cooker on a piece of packaging, exposing the base for fitting the feet. -
Page 10: Installation Instructions
Installation instructions Fitting the anti-tilt bracket Important! 6 0 0 m m To restrain the appliance and prevent it tipping (C a v it y w id th accidentally, fit a bracket to its rear to fix it securely to the wall. Make sure you also fit the supplied lock pin to the anti-tilt bracket. - Page 11 Installation instructions Connecting the cooker to the gas supply The gas connection must be carried out by an authorised person according to the relevant standards. Before connecting the appliance to the gas main, mount the brass conical adaptor onto the gas inlet pipe, upon which the washer has been placed (see Fig.s 4-5 following).
- Page 12 Installation instructions Gas connection for Gas connection for NATURAL GAS Gas inlet pipe Gas inlet pipe Nipple Nipple Washer Washer Brass conical adaptor Brass conical adaptor Test (Thread tight: use (Thread tight: use point suitable seal) suitable seal) Test point adaptor Gas pressure regulator Test...
- Page 13 Installation instructions Leak-testing and flame-testing the cooker After installing the freestanding cooker and connecting the gas supply: Using a suitable leak detection fluid solution, check each gas connection one at a time by brushing the solution over the connection. The presence of bubbles will indicate a leak. If there is a leak, tighten the fitting and then recheck for leaks.
- Page 14 Installation instructions Converting to a different gas type This appliance is suitable for use with Natural gas or LPG (check the “gas type” sticker attached to the appliance). To convert from one gas type to another, you need to replace the injectors, and then adjust the minimum burning setting.
- Page 15 Installation instructions Adjusting the minimum burner setting Check whether the flame spreads to all burner ports when the burner is lit with the gas valve set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas valve is turned quickly from the maximum to the minimum position.
-
Page 16: Wiring Diagram
Installation instructions Wiring diagram ELECTRIC DIAGRAM KEY Oven switch Oven thermostat Thermal overload Oven lamp Top element Grill element Bottom element Fan motor Cooling fan motor Thermostat pilot lamp Ignition switches group Ignition coil Terminal block Earth connection Fig. 10 Wiring diagram... - Page 18 Installation instructions Installation instructions Dimensions and clearances Installation clearances and protection of combustible surfaces shall comply with the current local regulations eg. AS/NZS 5601.1 Gas Installations code. Installation shall comply with the dimensions in Fig. 11, bearing in mind the following requirements: Overhead Clearances In no case shall the clearance above the highest part of the cooker be less than 600 mm or, for an overhead exhaust fan, 750 mm.
- Page 19 Installation instructions Dotted line showing Locating the area for gas and electrical connection the position of the cooker when installed Area for gas connection 70.5 mm 70.5 mm Area for electrical connection Fig. 12 Area for gas and electrical connections (*) Depending on feet adjustment Fitting the adjustable feet...
- Page 20 Installation instructions Installation instructions Moving the cooker Important! To prevent damaging the adjustable feet, ensure the cooker is always lifted by two people. Do not lift the cooker by the door handle. DO NOT DRAG the cooker. Lift the feet clear of the floor.
- Page 21 Installation instructions Fitting the anti-tilt bracket Important! To restrain the appliance and prevent it tipping accidentally, fit a bracket to its rear to fix it securely to the wall. Make sure you also fit the supplied lock pin to the anti-tilt bracket. If installing the cooker above a plinth (without fitting the adjustable feet), revise the installation dimensions accordingly...
- Page 22 Installation instructions Connecting the cooker to the gas supply The gas connection must be carried out by an authorised person according to the relevant standards. Before connecting the appliance to the gas main, mount the brass conical adaptor onto the gas inlet pipe, upon which the washer has been placed (see Fig.s 21-22 following).
- Page 23 Installation instructions Gas connection for Gas connection for NATURAL GAS Gas inlet pipe Gas inlet pipe Nipple Nipple Washer Washer Brass conical adaptor Brass conical adaptor Test (Thread tight: use (Thread tight: use point suitable seal) suitable seal) Test point adaptor Gas pressure regulator Test...
- Page 24 Installation instructions Leak-testing and flame-testing the cooker After installing the freestanding cooker and connecting the gas supply: Using a suitable leak detection fluid solution, check each gas connection one at a time by brushing the solution over the connection. The presence of bubbles will indicate a leak. If there is a leak, tighten the fitting and then recheck for leaks.
- Page 25 Installation instructions Converting to a different gas type This appliance is suitable for use with Natural gas or LPG (check the “gas type” sticker attached to the appliance). To convert from one gas type to another, you need to replace the injectors, and then adjust the minimum burning setting.
- Page 26 Installation instructions Adjusting the minimum burner setting Check whether the flame spreads to all burner ports when the burner is lit with the gas valve set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas valve is turned quickly from the maximum to the minimum position.
- Page 27 Installation instructions Wiring diagram ELECTRIC DIAGRAM KEY Oven switch Oven thermostat Thermal overload Oven lamp Top element Grill element Bottom element Fan motor Cooling fan motor Thermostat pilot lamp Ignition switches group Ignition coil Terminal block Earth connection Thermal overload...
-
Page 28: Using Your Oven
Using your oven Front left Rear right (semi- Temperature (auxiliary) rapid) indicator light burner knob burner knob Function Temperature Rear left (semi-rapid) Front right knob knob burner knob (triple-ring wok) burner knob Fig. 27a Control panel - OR60 models Temperature Front left (rapid) Rear right (semi-rapid) indicator light... - Page 29 Using your oven Slide in the shelves you will need, making sure that: they are between the two wires of a shelf position; the stop notches point down; the guard rail is at the back. Note: the grill tray should be positioned between the two wires of a shelf position and orientated as shown.
-
Page 30: Cooking Functions
Cooking functions OVEN LAMP Only the oven light(s) comes on. It remains on in all the cooking functions. BAKE The upper and lower heating elements come on. BAKE is the traditional method of cooking. It is best to cook on only one shelf at a time in this function. Ideal for large cakes and dishes that bake for several hours. -
Page 31: Using Your Gas Cooktop
Using your gas cooktop Fig. 30a Cooktop layout - OR60 models Fig. 30b Cooktop layout - OR90 models Auxiliary burner Semi-rapid burner Triple-ring wok burner Rapid burner Gas burners The knob controls the flow of gas through the safety valve. = closed valve (off ) = maximum flow = minimum flow... - Page 32 Using your gas cooktop Before using your cooktop Before using your new cooktop, please: Read this user guide, taking special note of the ‘Safety and warnings’ section. Turn the power to the cooker on at the wall. Make sure all burner controls are turned off. Using the gas burners Choose the control knob for the burner you want to use.
- Page 33 Using your gas cooktop If a burner does not light Check that: The cooker is plugged in and the electricity is switched on. The gas is turned on. The gas bottle is not empty (if you are using bottled gas). You have held down the knob for at least 10 seconds The ignitors are sparking.
- Page 34 Using your gas cooktop Matching cookware to burner Use flat-bottomed pans, and make sure they match the size of the burner, as shown in the following table. A small pot on a large burner is not efficient. Diameters of pans which may be used on the cooktop Burners Minimum Maximum...
-
Page 35: Cooktop Troubleshooting
Cooktop troubleshooting Problem Possible solutions A burner does not light. Check the cooker is switched on at the wall. Check the gas supply valve is turned on and the supply to the house is working. You should hear the gas when you turn a burner on. Check the gas bottle is not empty. -
Page 36: Care And Cleaning
Care and cleaning Important! Before you start cleaning your cooker, please: Read these cleaning instructions and the ‘Safety and warnings’ section at the start of this user guide. Turn the power to the cooker off at the wall. Make sure the cooker is a safe temperature to touch. Do not use a steam cleaner. - Page 37 Care and cleaning Burner parts and trivets You can remove and clean these parts with hot soapy water or non-abrasive detergents. Clean spills regularly before they become burnt on. Do not wash these parts in a dishwasher. After cleaning, check that the burners and their flame spreaders are dry before replacing correctly.
- Page 38 Care and cleaning Replacing the triple-ring wok burner Fit the burner ring to the housing as shown in the following figures. Make sure the burner is not able to rotate (Fig.38). Check that: The ignitor is always clean to ensure trouble-free sparking. The probe is always clean to ensure correct operation of the safety valves.
- Page 39 Care and cleaning Cleaning the fat filter (OR60 models only) Use only the supplied fat filter. Clean the fat filter after every use. If the filter is not cleaned, it will block and shorten the life of the fan element. If the filter is lightly soiled, place it in a dishwasher on normal wash.
- Page 40 Care and cleaning Fitting the side racks For ease of cleaning you may remove the side racks. Take care to replace them correctly after cleaning. Remove all shelves and trays. For easier access, you may remove the oven door. See ‘Removing the oven door’ . OR90 models Fig.
- Page 41 Care and cleaning Storage compartment (OR90 models only) The storage compartment is accessible through the pivoting panel (Fig.44). Important! Do not store flammable material in the oven or in the storage compartment. Pivoting panel Fig. 44 Storage compartment Replacing the oven lamps (OR90 models only) Turn the power to the cooker off at the wall.
- Page 42 Care and cleaning Replacing the oven lamp (OR60 models only) Turn the power to the cooker off at the wall. Let the oven cavity and the heating elements cool down. Twist the lamp cover (A) off. Remove and replace the bulb (B) with a new one suitable for high temperatures (300°C) with the following specifications: 220-240V, E14 and 15W.
- Page 43 Care and cleaning Removing and replacing the inner door glass pane for cleaning If you wish to clean the inner glass of the door, make sure you follow the precautions and instructions very carefully. Replacing the glass pane and the door incorrectly may result in damage to the appliance and may void your warranty.
- Page 44 Care and cleaning Removing and refitting the oven door Important! Take care, the oven door is heavy! To remove the door Close the door until the levers Open the door fully. hook to it. Open the levers. Disengage the hinges and remove the door.
- Page 45 Care and cleaning Cleaning the oven door glass (OR90 models) Removing the inner pane of glass The oven door is fitted with no. 2 panes: no. 1 outside; no. 1 inner. To clean all panes on both sides it is necessary to remove the inner pane as follows: Remove the inner glass retainer Remove the oven door and place it on a soft surface.
- Page 46 Care and cleaning Remove the inner glass pane Lift and remove the inner pane slightly, as shown in the Fig 48. Fig.48 Removing the inner glass pane...
- Page 47 Care and cleaning After cleaning, replace the inner glass pane When replacing the inner glass pane, make sure that: You replace the pane correctly, as shown. The pane must be in the position described below in order to fit into the door and to ensure that the appliance operates safely and correctly. You take extra care not to bump the edges of the glass against any object or surface.
- Page 48 Care and cleaning Replace the glass retainer Position the glass retainer, as shown in the Fig. 50. It should sit on the bottom edge of the outer glass. Check that the clamps ‘M’ are not deformed or damaged. Gently push the glass retainer back into place. You should be able to hear the tabs on both sides click as they lock the glass retainer in.
- Page 49 Care and cleaning Cleaning the oven door glass (OR60 models) Do not use harsh abrasive cleaners, or sharp metal scrapers to clean the oven door glass as they scratch the surface and result in shattering of the glass. Removing and refitting the inner glass panes of the oven door You may remove the inner glass pane for ease of cleaning.
- Page 50 Care and cleaning To refit the glass pane Make sure the open levers firmly Check the rubber pads are in place. hook to the door. Rubber pads Check the pane is the right way Insert the pane into the slide guides around .
-
Page 51: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance, please refer to the Service &... - Page 56 www.elba.co.nz www.elba.com.au Copyright © Fisher & Paykel 2014. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
