Main Technical Parameters - BAFANG MAX Drive System Dealer's Manual

1.4

Main technical parameters

Rated voltage (DCV)
Rated power (W)
Rated efficiency (%)
Rated rotating speed (rpm)
Maximum torque (nm)
Chain wheel
optional chain guard
Weight (Kg)
Sensors
noise (dB)
Working environment
Dust-proof/ water-proof grade
Certification
Functions
DEALER MAnuAL Max Drive SySteM
36 /
250 350 /
≥ 80%
100 ± 5
≥ 80
36t (recommended), 38t (optional), 42t (optional)
full chain guard / P-shaped chain guard
3.9
pedal assist speed sensor, pedal assist torque sensor and bicycle wheel
speed sensor and temperature sensor
< 55
-20°C~55°C
IP 66
CE RoHS/ En14766/ En14764/ REACH
Light function: DC 500mA/6V headlight & rearlight
optional functions: Bluetooth module, gear sensor, reprogramming function
DRIVE unIt (MM G33.350)
43
250 350
