Normal Operation - BAFANG MAX Drive System Dealer's Manual

6.4

normal operation

6.4.1 on/off Switch
turn on the device. Press and hold
to power on the display. Press and hold
2 seconds to power off the display. If the bike is not
used, after 5 minutes (time can be set) the display will
be automatically turned off.
6.4.2 assist Mode Selection
In the manual gearshift mode, press the
to choose the desired level of support by the motor.
the lowest level is Level 1, the highest Level 5. When
the display is on, the default mode is Level 1. When
there is no numeric mode display, there is no power
assistance.
Selecting the level for motor assistance
DEALER MAnuAL Max Drive SySteM
6.4.3
for 2 seconds
Briefly press
again for
speed. Single-trip distance (tRIP km)
(totAL km)
average riding speed (AVG km/h) are displayed in
successive order.
or
Switching between displays
DISPLAy (DP C01.RS232.7)
Switch between Distance Mode
and Speed Mode
to switch between distance and
➞ total distance
➞ maximum speed (MAXS km/h) ➞
46
