Connection Of The Eb-Bus To The Drive Unit; Connection Of The Headlight Cable To The Drive Unit - BAFANG MAX Drive System Dealer's Manual

3.3

Connection of the eB-BuS to the Drive unit

Link the EB-BuS cable to the EB-BuS connector at the drive unit.
3.4

Connection of the Headlight Cable to the Drive unit

Link the headlight cable to the connector for the headlight at the drive unit.
DEALER MAnuAL Max Drive SySteM
SyStEM CABLInG
male connector at the
D
EB-BuS 2105020000099
d female connector at the
drive unit for connection
to the EB-BuS
female connector at the
f
headlight cable
male connector for the
f
headlight at the drive
unit
