6 DiSplay (Dp C01.rS232.7)

6.1

Specifications and parameters of the Display

• 36 V / 48 V Power Supply;
• Rated Current: 10 mA
• Maximum operating Current: 30 mA
• Power-off Leakage Current: < 1uA
• operating Current Supplied to the Controller: 50 mA
• operation temperature: -18 ~ 60 %
• Storage temperature: -30 ~ 70 %
• Waterproof Grade: IP65
• Storage Humidity: 30 % – 70 %
6.2

appearance and Dimensions

6.2.1 Materials and Dimensions
• the shell is made of PC. the liquid crystal display is made of hardened PMMA.
