Adjust the angle of the display so that you can easily see the display screen when riding. After the angle has been
adjusted, tighten the screws to the specified torque.
tightening torque: 1 nm
2.4

auxiliary Keypad installation

keypad clamp
A
open the auxiliary keypad and assemble it onto a position that is easy for operation. Adjust the angle of the auxiliary
keypad to ensure that the keypad is easy to see seen during riding.
(Applicable to the handlebar whose external diameter is Ø 22.2mm)
