Attach coupling onto encoder shaft..................14 5.2.2 Mounting encoder onto drive shaft..................15 Maximum permitted tolerances for mounting errors when using the Baumer Hübner K 35 spring washer ..............................Notes when using a claw coupling (e.g. ROTEX®) ................18 6 Electrical installation........................... 19 Profibus DP............................
In addition, the local occupational health and safety regulations and general safety regulations apply. The illustrations in this manual are examples only. Deviations are at the discretion of Baumer at all times. Warnings in this manual Warnings draw attention to potential personal injury or material damage.
Baumer Hübner About this document Scope of delivery The scope of delivery includes: 1 x rotary encoder 1 x instruction manual 1 x General information leaflet In addition, you can find the following information, among other things, in digital format at www.baumer.com:...
About this document Baumer Hübner Maintenance and service life The device may only be opened for assembly and maintenance work as described in the present instruction manual. Any repair or maintenance work requiring fully opening the device must be carried out by the manufacturer only.
Used electrical and electronic devices may not be disposed of in household waste. The product contains valuable raw materials that can be recycled. There- fore dispose of this product at the appropriate collection point. For additional in- formation visit www.baumer.com. V1 | PMG10 & PMG10P Profibus DP Operating Manual...
Transport and storage Baumer Hübner Transport and storage Transport NOTICE Material damage due to improper transport. a) Ensure maximum diligence when unloading the delivered packages as well as when trans- porting them inside the company. b) Note the information and symbols on the packaging.
Description Baumer Hübner Mounting accessories (not included) Ill. 2: Mounting accessories Spring washer coupling K35, available as Mounting device, customer-specific (for accessory EURO flange B10 mount) Mounting screw M6x16 mm for attach- M6x20 mm screw for fastening the hous- ment device, ISO 4017 (for EURO flange...
Baumer recommends to use the Baumer Hübner K 35 spring disc coupling to connect the rotary encoder and the drive shaft of the following device. The Baumer Hübner K 35 spring disc cou- pling can be pushed onto the drive shaft without axial pressure.
Fasten the coupling at the specified torque (K 35: Mt = 1 Nm (plastic side), Mt = 1.3 ± 10% Nm (metal side)). Observe the remarks in the spring washer assembly instructions. Also see about this 2 Maximum permitted tolerances for mounting errors when using the Baumer Hübner K 35 spring washer [} 17] 5.1.2...
Baumer Hübner Installation Ill. 4: Installing encoder, mounting device and coupling Drive shaft Mounting screw M6x16 mm for attach- ment device (ISO 4017) Attachment device (customized) Coupling Tools 2.5 mm 10 mm Instruction: a) Prior to installation, check the drive runout error and dimensions.
Baumer recommends to use the Baumer Hübner K 35 spring disc coupling to connect the rotary encoder and the drive shaft of the following device. The Baumer Hübner K 35 spring disc cou- pling can be pushed onto the drive shaft without axial pressure.
Baumer Hübner Installation 5.2.2 Mounting encoder onto drive shaft DANGER Injuries caused by shaft rotation Hair and clothing may get caught in rotating shafts which may lead to serious personal injury. a) Make sure the device is idle. b) Before performing any work at the device, make sure power supply is and remains discon- nected.
Installation Baumer Hübner 90 mm Ill. 6: Mounting encoder onto drive shaft Drive shaft Coupling M6x20 mm screw for fastening the hous- Washer B6 for fastening the housing ing base (ISO 4017) base (DIN 137) Housing foot (according to product vari-...
Fasten the coupling onto the shaft of the drive at a torque of 1.3 ±10 % Nm. Observe the remarks in the data sheet and the coupling assembly instructions. Maximum permitted tolerances for mounting errors when using the Baumer Hübner K 35 spring washer NOTICE Damage to the encoder ball bearings.
Installation Baumer Hübner Notes when using a claw coupling (e.g. ROTEX®) NOTICE Damage to the rotary encoder due to incorrect mounting of the claw coupling. Blocking of the two coupling halves (coupling claws lie face to face) can damage the rotary en- coder.
Baumer Hübner Electrical installation Electrical installation DANGER Injury by to secondary damage Encoder failure or incorrect signals may entail system control errors. a) Eliminate secondary encoder damage by the relevant safety precautions in the downstream electronics. NOTICE Sensor damage due to faulty power supply.
Baumer Hübner Profibus DP 6.1.1 Profibus DP features INFO For detailed instructions and GSD files for the Profibus interface visit the Baumer website www.baumer.com. Fieldbus protocol Profibus DP V0 or Profibus DP V2 Features Profibus DP V0 = Device Class 1 and 2...
Baumer Hübner Electrical installation 6.1.2 Connecting the Profibus supply cable NOTICE Equipment damage by ESD The electronic components in the device are sensitive to high voltage a) Do not touch terminals or electronic components. b) Protect output terminals from external voltage.
Electrical installation Baumer Hübner 6.1.3.3 Mating connector (5-contact, B-coded) Ill. 13: Mating connector (5-contact, B-coded) Mating connector Connection Description Do not use Negative serial data line Do not use Positive serial data line Do not use 6.1.4 Terminal box Profibus DP Ill. 14: Terminal box PMG10 Profibus DP...
Baumer Hübner Electrical installation 6.1.4.1 Setting the terminating resistor ON = final bus user OFF = any bus user 6.1.4.2 Setting the bus user address 1. Digit user address 2. Digit user address (Illustration shows example user address 23). Terminal box 6.2.1...
Electrical installation Baumer Hübner 6.2.2 Output signals additional incremental output (optional) At positive rotating direction 90° Zero pulse+ Zero pulse- Ill. 15: Output signals with positive direction of rotation (zero pulse R+ and R- are only available at addi- tional output II) 6.2.3...
Baumer Hübner Electrical installation 6.2.6 Output switching behavior Speed switch (optional) INFO Default switching speed is 6000 rpm for HMG10P and PMG10P. HMG10 and PMG10 without programming interface come with the individually ordered permanent switching speed. Event Speed switching output state...
Baumer Hübner Electrical installation 6.2.8 Terminals assignment NOTICE Operating voltage present at the outputs results in encoder damage. The encoder might be damaged by any operating voltage being present at the outputs. a) Make sure that no operating voltage is present at the outputs.
Electrical installation Baumer Hübner Z-PA.SDL.1 WLAN adapter: Programming device for HMG10P/PMG10P INFO For detailed function descriptions refer to the WLAN adapter installation and operating instruc- tions. Ill. 18: Z-PA.SDL.1 WLAN adapter (ordering ref.: 11190106) The Z-PA.SDL.1 WLAN adapter is for programming and monitoring the HMG10P/PMG10P en- coder series.
Baumer Hübner Disassembly Disassembly NOTICE Equipment damage due to mechanical impact Strong vibration may lead to overload by constraining force. a) Never apply force. If properly performed, all components can be uninstalled smoothly. b) Use only suitable tools to uninstall.
Disassembly Baumer Hübner Uninstall when using EURO flange B10 7.1.1 Uninstall encoder from drive shaft DANGER Burns caused by heat The device heats up at high speeds. There is a risk of getting burned after use. a) Avoid overheating the device.
Page 33
Baumer Hübner Disassembly Tools 2.5 mm 10 mm Instruction: a) Disconnect all electrical connections. b) Loosen the the coupling on the drive shaft. Observe the notes in the data sheet and the coupling assembly instructions. c) Loosen the encoder from the drive's attachment device.
Disassembly Baumer Hübner Uninstall with base B3 7.2.1 Uninstall encoder from drive shaft DANGER Burns caused by heat The device heats up at high speeds. There is a risk of getting burned after use. a) Avoid overheating the device. b) Wear suitable protective gloves and clothing.
Page 35
Baumer Hübner Disassembly Tools 2.5 mm 10 mm Instruction: a) Disconnect all electrical connections. b) Loosen the the coupling on the drive shaft. Observe the notes in the data sheet and the coupling assembly instructions. c) Remove the encoder from the base.
Technical data Baumer Hübner Technical data PMG10 Electrical Data Operating voltage Ub 10-30 V DC (Ub (Bus)) 4,75-30 V DC (Ub (Ink)) Short-circuit proof Operating current without load ≤ 200 mA Initializing time ≤ 500 ms after switch-on Sensing principle Magnetic Fieldbus interface Profibus DPV0/V2 Data rate (fieldbus) 9,6-12000 kBaud...
Technical data Baumer Hübner Solid shaft encoder dimensions with housing base B3 Ill. 22: Solid shaft encoder dimensions with housing base B3 (all in mm unless specified otherwise) Operating Manual PMG10 & PMG10P Profibus DP | V1...
Page 39
Baumer Hübner List of illustrations List of illustrations Ill. 1 Description PMG10..........................Ill. 2 Mounting accessories ......................... 10 Ill. 3 Attach coupling onto encoder shaft ....................11 Ill. 4 Installing encoder, mounting device and coupling ................13 Ill. 5 Attach coupling onto encoder shaft ....................14 Ill.
