Quick Start — SW RGBHV Series Switchers, cont'd
Operation
Switch mode
Set the rear panel switch to Auto for autoswitch
mode (the switcher automatically switches to the
highest-numbered input with a sync
AUTO
signal present) or Normal for manual
switch mode. The front panel Auto
Switch Active LED lights when the
MANUAL
switcher is in autoswitch mode.
Switch inputs in normal switch mode
Press and release the desired input button.
Adjust audio level (SW2 RGBHV A /
SW4 RGBHV A / SW6 RGBHV A only)
1. Press and release the desired
input button.
2. Press and hold the Audio
Conf./Save button until the
Audio Conf./Save LED begins
to blink. The approximate level
is indicated by the input LEDs
and the polarity by the ±dB
LEDs. See "Audio gain and
attenuation (SW2 RGBHV A,
SW4 RGBHV A, and SW6
RGBHV A)" in chapter 3, "Operation", to read
the audio gain or attenuation level.
3. Press and release the
increase and decrease the audio level by 1 dB
per push of the button, or press and hold the
buttons to increase or decrease the level by 3 dB
per second.
1 2 3
4. Press and release the Audio
Conf./Save button to exit. The
Audio Conf./Save LED goes
out.
QS-2 SW RGBHV Series Switchers • Quick Start
Press
1
and release.
Press
and hold.
B
CONF/SAVE
Conf/Save blinks.
Release the button.
and buttons to
Press Press
4 6
5
-dB +dB
Press
and release.
CONF/SAVE
